1

English

Connect the Hardware

Connect the hardware according to the diagram in the opening chapter of this guide.

If  your  internet  connection  is  through  an  Ethernet  cable  from  the  wall  instead  of  through  a  DSL/Cable/Satellite

modem, connect the Ethernet cable directly to the router’s WAN port, and follow Step 3 to complete the hardware

connection.

1.  Turn off the modem, and remove the backup battery if it has one.

2.  Connect the modem to the  WAN port on your router with an Ethernet cable.

3.  Turn on the router, and wait for it to start.
4.  Turn on the modem.

Configure the Router

1.  Connect your computer to the router (Wired or Wireless).

•

Wired

:

Turn off  the Wi-Fi on your computer and connect your computer to the router’s LAN port using an

Ethernet cable.

•

Wireless

:

Connect your computer to the router wirelessly. The SSID (Network Name) is on the router’s label.

2.  Launch a web browser and enter

http://mwlogin.net

 in the address bar. Create a password for future logins.

Note: If the login window does not appear, please refer to FAQ > Q1.

3.  Follow the step-by-step instructions of

Quick Setup

 to set up your internet connection and wireless network.

Enjoy the internet!

Note: If you have changed the SSID and wireless password during the configuration, use the new SSID and wireless

password to join the wireless network.
