should already recharge the battery when it is reaching a

charge state of 30 %.

•  Storage: Always store batteries in a dry place and at

moderate temperatures between 10 °C and 20 °C.
Also consider the effect of self-discharge! When the ac-

cumulator is already empty, this effect may lead to a deep

discharge resulting in damaging the battery. If you intend

to store the battery for an extended period of time, you

can counteract this effect. We then recommend charging

the battery to approx. 40 % before storage. You should

check the state of charge after not more than a month.

Unpacking the Appliance

1.  Remove the appliance from its packaging.

2.

Remove all packaging material such as plastic films, filler

material, cable ties and cardboard packaging.

3.  Check the content for any missing parts.

4.  In the event that the packaging content should be incom-

plete or if damages are noticeable, do not operate the

appliance. Return it to the dealer immediately.

Overview of the Components /

Scope of Delivery

Top Side (Figure A)

1   button

2 Display

3   button

4  Shock absorber

5  Connection socket for power adapter

6  Main switch   /    (on / off)

7  Tab for opening the dust container compartment cover

8  Dust container compartment

Charging Station (Figure B)

9  Power adapter

10  Power indicator

11  Charging contacts
Bottom Side (Figure C)
12  Side brush

13  Contact area for charging via the charging station

14  Front wheel

15  Stairway detection sensor

16  Contact area for charging via the charging station

17  Side brush

18  Stairway detection sensor

19  Battery compartment cover

20  Drive wheel (left)

21  Air intake duct / rotating floor brush

22  Rubber lip

23  Drive wheel (right)

24  Stairway detection sensor

Remote Control (Figure D)

1   button

2  HOME button

3  OK button

4  button

5   button

6  PLAN button

7  button

8  CLOCK button

9   button

10  Direction buttons  ,  ,  ,

11  AUTO button
Not Illustrated

Filter insert with HEPA filter and fitting

Spare HEPA filter (1 ×)

Spare side brush (2 ×)

Cleaning tool

Notes for Use

•  The appliance is operated via charged battery. Charge

the battery using the power adapter provided. Direct

power supply via power adapter is not possible.

•  The appliance sucks up loose dirt through the nozzle.

For more efficient cleaning, the appliance is equipped

with a rotating brush and a rubber lip.

•  Do not use the appliance to vacuum building rubble.

•

Dirty filters reduce the suction power of the appliance,

hence we recommend cleaning the dust container and

filters after each use.

•  When the appliance hits a wall or other obstacles during

operation, it will change its driving direction.

•  Do not change the conditions of the room while the

appliance is in operation. For example, if you close a

door that previously allowed the appliance to move

unhindered, it will keep trying to get into the other room

until you open the door again.

•  The appliance also cleans underneath furniture if they

have a ground clearance of at least 80 mm. When the

appliance gets stuck under a piece of furniture, a beep

will sound, the display will show

 and the appliance

switches itself off.

•  When the appliance is lifted up during operation it will

emit a sound after a few seconds. The display will then

show

 and the appliance stops operating.

•  Due to its design, the cleaning of carpets and the driving

over edges is only possible to a limited extent. Short-pile

carpets with low edges can be surmounted. For long-pile

carpets, please use a conventional 230 V floor vacuum

cleaner.

•  The sensors at the bottom of the appliance detect steps

and other dips, so that it can not drop down.

CAUTION:

Prior to each use, ensure the sensors are clean, or

else the appliance may crash.
