ENGLISH

installed in the dust bin. Always check if the dust

bin (9) is assembled and installed properly.

 •

Use the wall-mounted holder (19) for easy

storing of the vacuum cleaner.

 •

During the operation or when carrying the

vacuum cleaner hold the unit by the han-

dle  (12).

 •

Press the on/off button (1) « » to switch the

vacuum cleaner on, the vacuum cleaner will

be switched on at the low power level, the

operation/charge indicator (3) will light up

green (pic. 3).

 •

During the vacuum cleaner operation you can

select the vacuum cleaner operating modes

by pressing the button (2) «+» (pic. 4). The

vacuum cleaner has two operation modes:

–

the operation time at the low power level is

approximately 35-40 minutes.

–

the operation time of the battery (11) at the

maximal power level is approximately 20 min-

utes of continuous operation, the operation/

charge indicator (3) will be glowing orange;

 •

Use the handle (12) for carrying the vacuum

cleaner.

CLEANING AND MAINTENANCE

Attention!

 Provide that the dust bin (9), the pre-

filter (16), the HEPA filter (17) and the outlet filter

(18) are always clean, because the overall per-

formance of the vacuum cleaner depends on it.

Remove garbage and dust from the dust bin  (9)

after each usage of the vacuum cleaner and

clean the dust bin (14), the separator (15), the

prefilter (16), the HEPA filter (17) and the outlet

filter (18) regularly.

 •

Remove the dust bin (9) by pressing the but-

ton (8) (pic. 5).

 •

To remove garbage and dust place the dust

bin (9) above the garbage bin, open the

lid  (13) holding by the release button, remove

garbage and dust and close the lid (13) until

the release button goes off.

Cleaning the dust bin (9)

 •

Before removing the dust bin (9) remove dust

and garbage from it as described above.

 •

Remove the outlet foam filter (18) and the

HEPA filter (17) turning it clockwise “ ”.

Clean the foam prefilter (16) and the HEPA fil-

ter (17) from dust and garbage.

 •

Remove the separator (15) from the dust bin

flask (14).

 •

Wash the dust bin flask (14), the prefilter (16),

the HEPA filter (17) and the outlet filter (18)

under warm running water jet. Do not wash all

removable parts in a dishwashing machine.

Note:

–

Before assembling and installing dry the dust

bin flask (14), the prefilter (16), the HEPA filter

(17) and the outlet filter (18) thoroughly.

–

Do not use heating units, including the haird-

ryer, to dry the removable parts.

–

Before assembling the dust bin (9) and install-

ing it to its place make sure that all removable

parts are clean and dry.

Assembling of the dust bin (9)

 •

Install the separator (15) into the dust bin

flask (14) having preliminary matched the

ledge on the separator with the groove on the

flask  (14).

 •

Put the foam prefilter (16) on the HEPa fil-

ter (17).

 •

Insert the HEPA filter (17) into the separa-

tor  (15) matching the marks on the HEPA fil-

ter  (17) and the separator (15) and turn it

counterclockwise until bumping “ ”.

 •

Install the outlet foam filter (18).

 •

Install the assembled dust bin (9) to its place

(pic. 5), make sure that the dust bin (9) is

fixed.

Cleaning the electric brush (7)

Keep the electric brush (7) clean; as it becomes

dirty, disassemble the brush (7) and clean the

round brush.

Remove the electric brush (7) from the extension

pipe (5) by pressing the release button (6).

Press on the lock (23) and open it.

Take out the round brush and remove threads

and hairs wound up around it.

Clean the inner and outer surface of the electric

brush (7) body from garbage and dust.

Assembling the electric brush (7)

 •

Insert the right part of the round brush into

the body.

 •

Install the left part of the round brush to its

place. Close the lock (23).

 •

Make sure that the round brush is fixed prop-

erly.

 •

Cleaning the vacuum cleaner body

 •

Wipe the vacuum cleaner body with a soft,

slightly damp cloth and then wipe it dry.
