Dear client,

thank you very much for your confidence.

You have made the really good choice:

The THOMAS Wet & Dry Vacuum-Cleaners are

efficient assistants for every household, craft and

professional cleaning task. The Wet & Dry models

SAUGSTAR 1250 S, INOX 1545 S and INOX 1545

SFE

are delivered with a

45 liter stainless-steel dirt

collecting bin, two-stage heavy-duty turbine

and

enhanced motor casing with protection against

splash water.

If this appliance brings you entire satisfaction, we

would be grateful to you to recommend us.

We prefer this sort of promotion to a big luxurious

advertising campaign.

A

Assembling the transpoert handle

Slide the transport handle from above into the

fixtures provided and screw securely into place.

B

Fitting the motor block

Place the motor block onto the collecting bin,

making sure that the operating switch lies

directly in line with the middle of the suction

socket. Lastly, secure the motor block by

means of both snap fasteners.

C

Connecting the flexible hose

Firmly insert the flexible hose in the suction

socket and turn the hose until the button clicks

into place and the markings on both the

suction socket and the hose connecting piece

correspond. (Remove the hose by turning the

hose connecting piece and slowly withdrawing

the hose).
Then attach the desired accessories and the

appliance is ready for use.

Operating the appliance

The MultiVac is switched on and off by means

of the switch located on the motor block

casing.
The mains supply voltage must correspond to

the voltage given on the rating plate.

D

Changing the cartridge filter

Pull out the plug!
Undo the fasteners, remove the motor block

from the collecting bin and turn over.
Gently pull the retaining clips back in the

direction indicated and carefully remove the

cartridge filter in an upright position from the

filter mounting. Place the new cartridge filter in

an upright position on the motor flange and

gently but firmly slide it into place on the filter

mounting.

The pre-mounted retaining clips automatically

snap into place, thus securing the cartridge

filter. Place the motor block on the collecting

bin again and secure by means of the snap

fasteners.

Inserting the paper filter bag

Place the filter bag inside the collecting bin,

making sure that the opening located in the

cardboard inlay is placed in line with the

suction soket.

The unit is fitted with a socket for external

appliance.
Electrical devices with wattages between

60 – 2000 W can be connected here.

Model 1545 SFE

The 1545 SFE model has two operating

modes, selected by means of selector switch

15 on the unit.

Selector switch 15
N: Normal operating (manual)

Immediate start-up of general purpose vacuum

cleaner for all cleaning tasks.

A: Automatic operation

The red light indicates that the appliance is

ready for operation.

Select this mode of operation when an

electrical tool fitted with a dust extraction

device is to be connected to the vacuum

cleaner.

Connect the electrical tool to the coupler

socket on the vacuum cleaner and attach the

suction hose to the appropriate outlet located

on the tool.

Now, when the electrical tool is switched

on/off, the vacuum cleaner will function

simultaneously.

The electronic switch-on control is suitable for

electrical tools with a power input of 60 –

2000 Watts maximum.

Changing the filter: model 1545 SFE

Firstly loosen the locking lever and pull the

retainer to the side. Remove straightly the filter

cartridge immediately. Fit a new or cleaned

filter cartridge onto the motor flange and push

along the filter rail as far as it will go. Finally,

re-secure with the retainer and locking lever.

Accessory case

Hang the accessory case onto the handle with

both eyelets at the top.

Assembly instructions

E

G

H

F
