10

Assembly Instructions

Dear client,
The THOMAS wet & dry vacuum cleaner

will give excellent cleaning results

throughout your home and workshop.

The Wet & Dry models

INOX 1420 plus/1520 plus

and

INOX 1520 S

are delivered with a

20-liter

stainless-steel dirt collecting bin,

and

enhanced

motor casing with protection against splash water.

Assembly Instructions

 A

Assembling the chassis

The parts to be assembled are supplied loose

for packing reasons . Open the snap fastener

and lift up the motor head .
Place the container with opening facing

downwards . Insert the steering castors

with bolts in the drill holes marked with the

number 4 and press in the bolts up to the

stop . Make sure that one steering castor

is directly in line under the suction intake

opening .

 B

Fitting the motor block

Place the motor block onto the collecting bin,

making sure that the operating switch lies

directly in line with the middle of the suction

socket . Lastly, secure the motor block by

means of both snap fasteners .

 C

Connecting the flexible hose

Connecting the flexible hose . Remove the

hose by turning the hose connecting piece

and withdrawing the hose .
Assemble the accessoires you require .
Connect the main cable .

     Operating the appliance

The Appliance is switched on and off by

means of the switch located on the motor

block casing .
The mains supply voltage must correspond to

the voltage given on the rating plate .

 D

Changing the cartridge filter

(Optional extra, Part no . 787021/421)
Pull out the plug!
Undo the snap fasteners, remove the motor

block from the collecting bin and turn over .
Secure the cartridge filter by the pre-mounted

retaining clips .
Place the new cartridge filter in an upright

position on the motor flange and gently

but firmly slide it into place on the filter

mounting . The pre-mounted retaining clips

automatically snap into place, thus securing

the cartridge filter . Place the motor block

on the collecting bin again and secure by

means of the snap fasteners .

 E

Inserting the paper filter bag

(when changing the paper filter bag)
Place the filter bag inside the collecting bin,

making sure that the opening located in the

cardboard inlay is placed in line with the

suction socket .

Then press the filter bag evenly

around the sides of the collecting bin.

Thomas paper filter bags are

essential

when vacuuming fine dust, e .g . soot, ashes,

sawdust or cement . However, they are also

recommended for normal use, as they not

only improve the retention of dust, but also

make filter changes more hygienic .

Changing the cartridge filter

Gently pull the retaining clips back in the

direction indicated and carefully remove the

cartridge filter in an upright position from the

filter mounting .

+

F
