– 4 –

E

Information for your safety

Please read all the following information,
which contains important instructions for the
safety, the use and the maintenance of the
appliance.
This appliance complies with the following EC
Directives: -73/23/EEC, 93/68/EEC-Low
Voltage Directive-89/336EEC -EMC Directive.

■

Never allow children to use the appliance
unsupervised.

■

Do not use the appliance If the supply
cord is damaged or faulty.

■

If the main lead is damaged, it must be
replaced by an approved LG Electronics
Service Agent in order to avoid a hazard.

■

Always switch the vaccum cleaner off
before :
• changing the dust bag.
• changing or cleaning the filters.

■

If no dustbag is inserted, the cover
cannot be closed. Please do not use
force!

■

Do not vacuum flammable or explosive
substances(liquids or gases).

■

Do not vacuum hot ash, embers etc. nor
sharp objects.

■

Do not vacuum water or other liquids.

How to Use

Connecting the flexible hose

Push the end of the head

(1)

on the flexible

hose

(2)

into the attachment point on the

vacuum cleaner.
To remove the flexible hose from the vacuum
cleaner, press on the button

(3)

situated on the

head, then pull upwards.

Assembling the tubes

(depending on model)

• Metal

and plastic

tube(4)

- Fit together the tubes by twisting slightly.

• Telescopic tube(5)

- Push spring latch(6) forward.
- Pull out tube to required length.
- Release spring latch to lock.

Using the cleaning head and
Accessory Nozzles

(depending on model)

Fit the large cleaning head onto the end of the tube.

•

The 2 position head(7)

is equipped with a

pedal

(8)

which allows you to alter its position

according to the type of floor to be cleaned.

Hard floor position

(tiles, parquet floors...).

Press on the pedal to lower the brush.

Carpet or rug position.

Press on the pedal

to lift the brush up.

•

Crevice Tool(9)

For vacuuming in those normally inaccess-
ible places i.e. reaching cobwebs, or down
the side of a sofa!

•

Dusting brush(10)

For vacuuming picture frames furniture
outlines, books and other uneven objects.
(depending on model)

•

Upholstery Nozzle(11)

For vacuuming uphostery, mattresses, etc.
The thread collectors help to pick up the
threads and fluff. (depending on model)

How to plug in and use

Pull out the supply cord to the desired length
and plug into the socket.
Press button

(13)

to start the vacuum cleaner.

To stop it press the button

(13)

again.

Adjusting the power level

• The flexible hose handle

(14)

has a manual

air flow regulator

(15)

which allows you to

briefly reduce the suction level.

• If your appliance is equipped with an

electronic variable power control

(16)

, you

can choose the power appropriated for the
task. (depending on model)

Park-System(17)

For short breaks during vacuuming, for
example to move a small piece of furniture of a
rug, use the  Park system to support the
flexible hose and cleaning head.
• Slide the hook attached to the large cleaning

tool into the slot on the rear of the appliance.

Storage(18)

When you have switched off and unplugged
the appliance, press on the button

(12)

to

automatically rewind the cord.
You can move or store your appliance in a
vertical position by sliding the hook on the
large cleaning head into the clip on the
underside of the appliance.
