– 9

Illustration



Insert the fresh water container into the appliance.



The fresh water tank must sit snugly into the appliance.

ATTENTION

*Follow the recommended dosage instructions on the
detergent/care agent.

ATTENTION

Illustration

The device can only vacuum dried dirt and liquids (max.
140 ml).

Illustration

Brush or vacuum the floor before starting work. This re-
moves dirt and loose particles from the floor before the
wet cleaning commences.
Before use, check the floor for water consistency at sus-
pect areas. Do not clean water-sensitive coatings, such
as untreated cork floors (moisture ingress is possible
which may damage the floor).

Illustration
To avoid fresh footprints on the freshly-wiped floor, work
backwards towards the door.



Clean the floor by moving the appliance back and
forth at a similar speed as if you were vacuum
cleaning.



If the floor is especially dirty, let the appliance glide
slowly across the floor.
Pressure does not need to be exerted on the device.



For scope of delivery of the roller pads in grey and yel-
low: Both roller pads have the same functionality, they
can be used for different areas of application (colour
distinction, e.g. for kitchen and bathroom).

ATTENTION

After switching on the appliance, the cleaning rollers will
begin to rotate. Hold the handle tight to prevent the ap-
pliance from moving forwards by itself.
Make sure the fresh water tank is filled with water and
the waste water tank is fitted in the appliance.

Illustration



To switch on the appliance press the on/off switch.



Move the unit back and forth several times until the
rollers are sufficiently moistened.

Illustration
–

3 LEDs illuminated - 3/3 battery run time (full run
time).

–

2 LEDs illuminated - 2/3 battery run time.

–

1 LEDs illuminated - 1/3 battery run time.



The lowermost LED starts to flash approx. 2 min-
utes before the battery has to be charged.



The last LED flashes quicker for 60 seconds when
the battery is empty and the device has switched
off.

ATTENTION

Before filling the fresh water tank, please empty the
waste water tank. In this way you can avoid overflowing
of the waste water tank.

See chapter "Filling the fresh water tank".
See Chapter "Emptying the waste water tank".

Illustration



Place the device in the parking station.

Illustration



Actuate the floor head cover latch.



Remove the floor head cover.

Illustration



Remove the waste water tank from the floor head.

Illustration



Fold the flaps over the two waste water tank chambers.



Empty the waste water tank.

Illustration



Clean the floor head cover and waste water tank
with tap water, depending on the degree of soiling.



The flaps of the two waste water tank chambers
can be removed and cleaned separately.



Re-insert and close the flaps of the two waste water
tank chambers.

Illustration



Insert the waste water tank into the floor head.

Illustration



Actuate the latch on the floor head cover, fit the cover
onto the floor head and then release the latch.



The waste water tank and floor head cover must sit
firmly in and on the device.

ATTENTION

To prevent damage to sensitive floors through wet roll-
ers, we recommend placing the device in the parking
station during longer work breaks.

Illustration



Switch off the appliance; press the on/off button to
do so.

Illustration



Place the device in the parking station.

Illustration



Switch off the appliance; press the on/off button to
do so.

Illustration



Place the device in the parking station.

ATTENTION

Clean the device after completing the work.

Illustration



Drain any water remaining in the fresh water tank.

Figure

 to



Clean the waste water tank, floor head cover and
cleaning rollers.
See chapter "Cleaning the waste water tank".
See chapter "Cleaning the floor head".
See chapter "Cleaning the rollers".

ATTENTION

To prevent odours developing, the fresh water and
waste water tank must be completely emptied prior to
storing the appliance.
Allow wet rollers to dry in the air (e.g. on the parking sta-
tion), do not place wet rollers in closed cupboards to dry.

Illustration



Place the device in the parking station.

Illustration



Place the wet rollers on the parking station to dry.



Store the appliance in a dry room.

Operation

General information on the

 operation

Start working

Battery service life

Refill detergent

Emptying the waste Water tank

Interrupting operation

Turning Off the Appliance

Storing the Appliance

16

EN
