•  Do not use the appliance in damp rooms!

•

Never use without the filter. Check that the filter is inserted cor

-

rectly!

•  Keep hair, clothing and body parts away from the vacuum nozzle

during use!

•  Keep the vacuum cleaner away from sources of heat like radia-

tors, ovens, etc.!

Overview of the Components /

Scope of Delivery

1  Suction hose

2  Telescopic suction pipe

3  Slide for telescopic suction pipe

4  Floor nozzle

5  Lever for extending and retracting the brushes

6  Hook

7  Handle

8  Opener dust bag compartment

9  Connection head of the vacuum hose

10  Hose connection

11  Dust bag filling display

12  Cover for outlet filter

13  Lock for outlet filter cover

14  On / off switch

15  Stowage clip

16  Suction control

17  Cable-winding button

Accessories:

18  Combined crevice and brush nozzle

19  Hard floor brush

Start-up

•  Insert the connection head of the suction hose into the

hose connector until it locks in place. To do so, please

press the buttons simultaneously. In order to release the

hose again, please press the buttons once more on the

connection head.

•  Keep the buttons pressed down and then pull out the

hose.

•  Insert the vacuum tube into the handle if required.

•

Then assemble the floor nozzle and/or the accessories.

To detach the nozzle attachments from the suction pipe,

pull them off by turning them slightly.

Nozzle Attachments

Floor Nozzle (4)

The floor nozzle features castors for easier movement.

You can clean smooth surfaces and carpets with the floor

nozzle.
•  Adjust the brushes outwards or inwards using the

lever (5).

Best use of the appliance depends on the texture of the

floor covering. We recommend the following use:

•  Use without brushes:

For vacuuming floor coverings

with a deep pile

•  Use with brushes:

For vacuuming smooth floors

and carpets with a shallow pile

Hard Floor Brush (19)

For gentle cleaning of hard surfaces such as parquet,

laminate, tiles, etc.

Crevice and Brush Nozzle (18)

  NOTE:

Folding “2 in 1” nozzle

When this is folded together it can be used as a groove

nozzle. If you would like to use the brush nozzle, pull the

brush section in the direction of the arrow until it locks in

place.

•

Crevice nozzle:

For vacuuming dirt from corners, joints and small gaps.

•

Brush nozzle:

For removing dirt gently from slits in upholstery and mat-

tresses. Also suitable for removing dust from sensitive

surfaces such as furniture or curtains.
