Crevice and Brush Nozzle (21)

  NOTE: Folding “2 in 1” nozzle

When this is folded together it can be used as a groove

nozzle. If you would like to use the brush nozzle, pull the

brush section in the direction of the arrow until it locks in

place.

•

Crevice nozzle:

For vacuuming dirt from corners, joints and small gaps.

•

Brush nozzle:

For removing dirt gently from slits in upholstery and mat-

tresses. Also suitable for removing dust from sensitive

surfaces such as furniture or curtains.

Turbo Brush

The turbo brush is equipped with a rotating roller brush

powered by the air stream. It is particularly suitable for ab-

sorbing hair, threads and lint on upholstery. To absorb hair

better, pay attention to the position of the brush attachment.

The brushes must be folded down. You can fasten or loosen

the attachment with the locking mechanism ( ) on the right

side of the brush roller.

  CAUTION:

Do not use the turbo brush on sensitive smooth floors

such as parquet, laminate or similar.

The surface could be damaged.

Mains Cable

Pull the mains cable from the cable compartment. The cable

compartment is located at the back of the appliance below.

  CAUTION:

•  Pull out the cable up to the maximum length indicated

with the yellow mark.

•  Never pull the cable out up to the red mark as the

cable winding can be damaged.

  NOTE:

If the red mark is visible, pull in the cable with the help of

the cable winding button back to the yellow mark.

Electrical Connection

•  Before connecting the plug to the wall socket, check

whether the mains voltage is correct. Refer to the infor-

mation on the rating plate of the appliance.

•

Connect the appliance to a certified wall socket only.

Using the Appliance

1.  Insert the mains plug into a correctly installed power

socket.

2.

Turn the appliance on by the on / off switch by pressing

down the button.

3.

Set the “carpet / hard floor” switch, depending on the floor

covering.

4.  Adjust the suction power with the suction power control.

5.  Vacuum at a steady speed. There is no need to exert

pressure.

  NOTE:

Pay attention to the range that can be covered with the

cable length!

Air Slide

Open the air slide on the hose handle in

order to regulate the airflow or to clear any

particles sticking to the nozzle.

Switching Off and Winding Up the Mains Cable

1.

Turn the vacuum cleaner off by the on / off switch and

remove the plug from the socket.

2.  Keep the plug in your hand.

3.

Press the cable winding button and guide the cable. Hold

the cable to avoid wrapping.

Maintenance

Emptying the Dust Collector

Empty the dust collector once the collected dirt reaches the

MAX marking.
1.  Disconnect the mains plug from the wall socket.

2.  Press the button (10) to release the dust collector.

Remove the dust collector.

3.  Empty the dust collector over a dustbin. Press the latch

on the dust container to open the bottom plate. (Page

4, Fig. B).

4.  Then close the base plate again.

5.  Attach the dust collector to the appliance. First position

it at the bottom of the appliance and then secure it with

the hook on top.

6.  Check that the position of the dust collector is secure by

briefly lifting the appliance at its carrying handle.

Filters

Your appliance features 4 filters. The common dust bag

system has been replaced by a transparent dust collector.

The higher flow speed of the collector allows for heavy dirt

and smallest floating particles to be separated from the

“sucked-in air”.

It is thus not necessary to buy dust bags.

The filters must be cleaned regularly.
