•  Do not use the appliance in damp rooms!

•

Never use without the filter. Check that the filter is inserted cor

-

rectly!

•  Keep hair, clothing and body parts away from the vacuum nozzle

during use!

•  Keep the vacuum cleaner away from sources of heat like radia-

tors, ovens, etc.!

Unpacking the Appliance

1.  Remove the appliance from its packaging.

2.  Remove both protection parts from the bottom of the

appliance.

3.  Check the delivery scope for completeness.

4.  Check the appliance for any transport damage, in order

to prevent hazards.

  NOTE:

In case of any transport damage, contact your dealer

immediately. Do not use a damaged appliance!

Overview of the Components /

Scope of Delivery

1  Air slide

2  Handle

3  Suction hose

4  Connection head of the vacuum hose

5  Hose connection

6  Dust collector base plate

7  Dust container

8  Cover lock (Filter unit)

9  Carrying handle

10  Dust collector release button

11  Cable-winding button

12  Suction power control

13  Ventilation grill lock (Filter unit)

14  Mains power supply cable

15  Positioning aid

16  On / off switch

17  Carpet / hard floor selector

18  Floor nozzle (with hook (not shown))

19  Telescopic suction tube

20  Parquet brush

21  Combined crevice and brush nozzle

Not shown

Turbo brush

Start-up

•  Insert the connection head of the suction hose into the

hose connector until it locks in place. To do so, please

press the buttons simultaneously.

•  In order to release the hose again, please press the

buttons once more on the connection head. Keep the

buttons pressed down and then pull out the hose.

•  Insert the vacuum tube into the handle if required.

•

Then assemble the floor nozzle and / or the accessories.

To detach the nozzle attachments from the suction pipe,

pull them off by turning them slightly.

Nozzle Attachments

Floor Nozzle (18)

The floor nozzle features castors for easier movement.

You can clean smooth surfaces and carpets with the floor

nozzle.
•  Adjust the brushes outwards or inwards using the

lever (17).

Best use of the appliance depends on the texture of the

floor covering. We recommend the following use:

•  Use without brushes:

For vacuuming floor coverings

with a deep pile

•  Use with brushes:

For vacuuming smooth floors

and carpets with a shallow pile

Parquet Brush (20)

For gentle cleaning of sensitive hard floors like parquet,

laminate, tiles, etc.
