Crevice nozzle:

For vacuuming dirt from corners, joints and small gaps.

•

Brush nozzle:

For removing dirt gently from slits in upholstery and mat-

tresses. Also suitable for removing dust from sensitive

surfaces such as furniture or curtains.

Telescopic Suction Pipe (17)

The length of the telescopic suction pipe can be adjusted

individually:
1.  Loosen the locking mechanism by

sliding and holding the button in the

direction of the arrow marking.

2.

Extract one tube from the other to the

desired length.

3.  Release the button in order to lock the

connection.

Mains Cable

Pull the mains cable from the cable compartment. The cable

compartment is located at the back of the appliance below.

  CAUTION:

•  Pull out the cable up to the maximum length indicated

with the yellow mark.

•  Never pull the cable out up to the red mark as the

cable winding can be damaged.

  NOTE:

If the red mark is visible, pull in the cable with the help of

the cable winding button back to the yellow mark.

Electrical Connection

•  Before connecting the plug to the wall socket, check

whether the mains voltage is correct. Refer to the infor-

mation on the rating plate of the appliance.

•

Connect the appliance to a certified wall socket only.

Using the Appliance

1.  Insert the mains plug into a correctly installed power

socket.

2.  Turn the appliance on by the on / off switch by pressing

down the button.

3.

Set the “carpet / hard floor” switch, depending on the floor

covering.

4.  Adjust the suction power with the suction power control.

5.  Vacuum at a steady speed. There is no need to exert

pressure.

  NOTE:

Pay attention to the range that can be covered with the

cable length!

Air Slide

Open the air slide on the hose handle in

order to regulate the airflow or to clear any

particles sticking to the nozzle.

Switching Off and Winding Up the Mains Cable

1.

Turn the vacuum cleaner off by the on / off switch and

remove the plug from the socket.

2.

Keep the plug in your hand.

3.

Press the cable winding button and guide the cable. Hold

the cable to avoid wrapping.

Maintenance

Emptying the Dust Collector

Empty the dust collector once the collected dirt reaches the

MAX marking.
1.  Disconnect the mains plug from the wall socket.

2.

Disconnect the hose from the hose connection.

3.  Press the button (7) to release the dust collector. Re-

move the dust collector.

4.  Empty the dust collector over a dustbin. To do this, pull

the latch on the dust collector to open the base plate.

5.  Then close the base plate again.

6.

Attach the dust collector to the appliance. First position

it at the bottom of the appliance and then secure it with

the hook on top.

7.  Check that the position of the dust collector is secure by

briefly lifting the appliance at its carrying handle.

Filters

Your appliance features 4 filters. The common dust bag

system has been replaced by a transparent dust collector.

The higher flow speed of the collector allows for heavy dirt

and smallest floating particles to be separated from the

“sucked-in air”.

It is thus not necessary to buy dust bags.

The filters must be cleaned regularly.

Filter Insert

  CAUTION:

•

Never wash the filter in the washing machine.

•  Do not use a hairdryer for drying.

•

Only use the appliance after the filters have been

installed correctly.

Proceed as follows to remove, clean and reinstall the filter

insert:
1.  Empty the dust collector as described previously.

2.

Remove the dust collector lid. Turn it anticlockwise in the

direction of  .
