•  Do not use the appliance in damp rooms!

•

Never use without the filter. Check that the filter is inserted cor

-

rectly!

•  Keep hair, clothing and body parts away from the vacuum nozzle

during use!

•  Keep the vacuum cleaner away from sources of heat like radia-

tors, ovens, etc.!

Unpacking the Appliance

1.  Remove the appliance from its packaging.

2.

Remove both protection parts from the bottom of the

appliance.

3.  Check the delivery scope for completeness.

4.  Check the appliance for any transport damage, in order

to prevent hazards.

  NOTE:

In case of any transport damage, contact your dealer

immediately. Do not use a damaged appliance!

Overview of the Components /

Scope of Delivery

1  Air slide

2  Handle

3  Suction hose

4  Hose connection

5  On / off switch

6  Carrying handle

7  Dust collector release button

8  Cable-winding button

9  Suction power control

10  Ventilation grill lock (outlet filter)

11  Positioning aid

12  Dust container

13  Dust collector base plate

14  Connection head of the vacuum hose

15  Carpet / hard floor selector

16  Floor nozzle (with hook (not shown))

17  Telescopic suction tube

18  Parquet brush

19  Combined crevice and brush nozzl

Start-up

•  Insert the connection head of the suction hose into the

hose connection of the appliance. Tighten the connection

header anticlockwise.

•  To release the hose again, turn the connecting header

clockwise.

•  Insert the vacuum tube into the handle if required.

•

Then assemble the floor nozzle and / or the accessories.

To detach the nozzle attachments from the suction pipe,

pull them off by turning them slightly.

Nozzle Attachments

Floor Nozzle (16)

The floor nozzle features castors for easier movement.

You can clean smooth surfaces and carpets with the floor

nozzle.
•  Adjust the brushes outwards or inwards using the

lever (15).

Best use of the appliance depends on the texture of the

floor covering. We recommend the following use:

•  Use without brushes:

For vacuuming floor coverings

with a deep pile

•  Use with brushes:

For vacuuming smooth floors

and carpets with a shallow pile

Parquet Brush (18)

For gentle cleaning of sensitive hard floors like parquet,

laminate, tiles, etc.

Crevice and Brush Nozzle (19)

  NOTE: Folding “2 in 1” nozzle

When this is folded together it can be used as a groove

nozzle. If you would like to use the brush nozzle, pull the

brush section in the direction of the arrow until it locks in

place.
