  NOTE:

•  We recommend recharging the battery once the indica-

tor lights show a remaining capacity of only 25 %.

•  Once the rechargeable battery is almost out of power,

the last indicator light will start flashing for a few sec

-

onds. To avoid a deep discharge of the rechargeable

battery, the motor will shut off the appliance accord-

ingly. Recharge the battery.

End of Operation

1.

Turn off the appliance.

2.  If you have already installed the wall holder, hang up the

vacuum cleaner.

Maintenance

Emptying the Dust Container

1.  Disconnect the appliance from the power adapter.

2.  If necessary, remove the suction tube or the nozzle

attachment from the appliance.

3.

Hold the appliance with the bottom plate of the dust con

-

tainer over a dustbin.

4.  Empty the contents of the

dust container. Press the but-

ton (9) on the dust container

to open the base plate.

5.

Then close the base plate

again. The lock on the dust

container must engage.

The Filter System

Your appliance features 3 filters. The common dust bag

system has been replaced by a transparent dust container.

The higher flow speed of the container allows for heavy

dirt and smallest floating particles to be separated from the

“sucked-in air”.
It is thus not necessary to buy dust bags.

The filters must be cleaned periodically.

  CAUTION:

•

Never wash the filter in the washing machine.

•  Do not use a hair-dryer for drying.

•  Only put the appliance back into operation when all

filters are completely dry and correctly assembled.

The Filter Unit

The filter unit is located in the dust container and consists

of:
•

HEPA-filter

•

Coarse filter

Proceed as follows to clean the filter unit:

1.

Empty the dust container as described above.

(Steps  1 - 5)

2.  Disassembly of the Filter Unit

2.1  Hold the handset in such a way that the handle is on

the right hand side, in front of you. Different symbols

can be found on the dust container. Turn the dust

container clockwise until the   symbol is positioned

below the

 mark on the handset. The dust container

can now be separated from the housing.

2.2  Remove the HEPA filter.

2.3  Remove the coarse filter from the dust container.

3.  Cleaning the Filters

3.1  Hold both filters over a garbage can and tap out the

dust. You may also brush out the HEPA filter. In case

of heavy staining, clean the filters under running

water.

3.2  Let the filters air-dry completely before refitting them!

3.3  Wipe the dust container with a damp cloth and then

wipe it dry.

4.  Assembly of the Filter Unit

4.1  Place the coarse filter in the dust container. Please

note the recess on the edge of the dust container.

Now push the coarse filter down so that it is placed

in the centre of the dust container.

4.2  Place the HEPA filter back into the coarse filter.

4.3  Then reattach the dust container to the handset.

Attach the dust container to the handset with the

symbol positioned below the   mark on the handset.

Then turn the dust container anti-clockwise as far as

it will go. The

 symbol on the dust container must

be located below the   marking on the handset.

Outlet Filter

The appliance is also equipped with an exhaust filter. It is

located at the top of the motor housing.
1.  Press the

PUSH

 button (17) to be able to remove the

cover.

2.

Remove the ring-shaped foam filter and wash it out.

3.

Allow the foam filter to air-dry completely before reinsert

-

ing it into the appliance.

4.  Put the cover back onto the motor housing. The latch

below the

PUSH

 button must audibly engage.
