When the charging process of the battery is completed,

you should disconnect the charger immediately. A charge

up to 90 % is considered best.

Conversely, it is also preserving the battery more when

it is not discharged to 0 %. If the possibility arises, you

should already recharge the battery when it is reaching a

charge state of 30 %.

•

Storage:

Always store batteries in a dry place and at

moderate temperatures between 10 °C and 20 °C.

Also consider the effect of self-discharge! When the ac-

cumulator is already empty, this effect may lead to a deep

discharge resulting in damaging the battery. If you intend

to store the battery for an extended period of time, you

can counteract this effect. We then recommend charging

the battery to approx. 40 % before storage. You should

check the state of charge after not more than a month.

Unpacking the Appliance

1.  Remove the appliance from its packaging.

2.  Check the delivery scope for completeness.

3.  Check the appliance for any transport damage, in order

to prevent hazards.

  NOTE:

In case of any transport damage, contact your dealer

immediately. Do not use a damaged appliance!

Overview of the Components /

Scope of Delivery

1  Indicator lights

2  ECO button

3  On / off button

4  Carrying handle

5  Power supply connection socket

6  Release buttons for the rechargeable battery pack on

both sides

7  Dust container

8  Base plate of the dust container

9  Opener / locking of the base plate

10  Suction pipe release

11  Suction pipe

12  Floor nozzle release

13  Floor nozzle with turbo brush

14  Crevice nozzle

15  Accessory holder

16  Combined upholstery / brush nozzle

17

PUSH

 opener / locking of the cover (Outlet filter)

18  Exhaust filter behind the cover

19  Motor housing / hand set

Not Shown

1 ×  Special  brush

1 ×  Power  adapter

1 ×  Wall  holder

2 ×  Wall  plug

2 ×  Screw

Notes for Use

•

The appliance is especially suitable for quickly vacuum

-

ing small amounts of dry dirt or dust.

•

The appliance is operated via charged battery. Charging

is done via the supplied power adapter.

•  Direct power supply via power adapter is not possible.

•

This rechargeable battery vacuum cleaner is no

adequate replacement for a conventional floor vacuum

cleaner. Especially on shag-pile carpet, the cleaning

performance is not sufficient owing to its design.

•

Contaminated filters reduce the suction power of the vac

-

uum cleaner. Therefore, we recommend regular cleaning

of the existing dirt filters.

•

Ideally, clean the filters whenever they have been subject

to a prolonged use.

•

Please regularly check and clean the electric floor

nozzle.

•

If necessary, clean heavily soiled floors multiple times

and / or use a conventional 230 V~ floor vacuum cleaner.

Switching  the Appliance  On / Off

•

The button

 turns the appliance on and off.

•  Press the

ECO

 button to toggle between low and high

power level. In ECO mode, you can extend the life cycle

of the rechargeable battery. The LED between the two

buttons will light up.

Start-Up

Suction Pipe

•  Insert the suction pipe with the two contact pins into

the connection on the hand appliance. It must audibly

engage.

•

To disconnect the suction pipe, press the release (10)

and pull out the pipe at the same time.

•

Use the bracket to attach the upholstery / brush nozzle

and the crevice nozzle to the suction tube. This way, you

always have the accessories at hand.

Floor Nozzle with Turbo Brush

•

The floor nozzle is suitable for all floor coverings except

for shag-pile carpets.

•

During operation, the LEDs on the floor nozzle light up

for better visibility in dark areas.

  CAUTION:

You

cannot

 replace the LEDs.

•  Stick the lower end of the suction pipe onto the connec-

tor on the floor nozzle. Note the contact pins on the floor

nozzle. The suction pipe must audibly s snap into place.

•

To disconnect the suction pipe, press the release (12)

and pull out the pipe at the same time.
