Components 1 and 2

•  These components can be rinsed off under running

water. If need be, clean the components in warm soapy

water using a soft brush.

•  Allow the components to dry before you reassemble the

appliance.

Floor Nozzle

1.  Press the unlock button (15) to pull the floor nozzle off

the appliance holder.

2.  Turn the floor nozzle around, so that you see the lower

side. Remove the cover

 by pressing the latch

down.

3.  Pull out the brush roller.

4.  Remove threads and hair wound to the brush. Use

scissors, if required.

5.

Assembly:

5.1  Place the brush roller, with the triangular recess

first, onto the right side. Make sure that the triangu-

lar recess on the brush roller is positioned correctly.

5.2  Return the bearing of the brush roller into the hous-

ing of the floor nozzle.

6.  Place the cover

 back on. The latch must audibly

engage.

Storage

•  Clean the appliance as described and allow it to dry.

•  You may use the mounted charging station for storage.

•  We recommend that you keep the appliance in the origi-

nal packaging if it will not be used for long periods.

•  Always store the appliance out of the reach of children in

a dry, well ventilated place.

Troubleshooting

Problem

Possible Cause Remedy

The

appliance

does not

function.

The rechargeable

battery is empty.

Charge the battery.

Weak

suction

power.

The rechargeable

battery is nearly

discharged.

Charge the battery.

The filters are

dirty.

Clean the filters as de-

scribed under “Cleaning”.

 CAUTION:

Restart operation only

with dry filters.

Noise

during

operation.

A foreign body

has been sucked

into the floor

nozzle.

Remove the foreign

body. If required, sepa-

rate the floor nozzle from

the appliance holder.

Technical Data

Model:.............................................................. PC-BS 3035 A

Net weight: ....................................................... approx. 2.8 kg

Power adapter

Protection class: ..............................................................

Input:......................AC 100 - 240 V, 50 / 60 Hz, 0.35 A MAX

Output: .....................................................DC  18 V,  500 mA

Polarity:..................................................................

Battery:

 ......................................... 4 × 3.7 V, 2200 mAh Li-Ion

Operating time: ................................ 20 minutes maximum

Charging time: .....................................................4.5 hours

The right to make technical and design modifications in

the course of continuous product development remains

reserved.
This appliance has been tested according to all relevant

current CE guidelines, such as electromagnetic compatibil-

ity and low voltage directives, and has been constructed in

accordance with the latest regulations.

Disposal

Accumulator / Battery  Disposal

The appliance contains a rechargeable battery.

Used batteries /  accumulators (rechargeable

batteries) do not belong in household waste.
The battery must be removed before the prod-

uct is recycled. Contact qualified personnel.

Information, where batteries / accumulators are to be

disposed of can be obtained from your local or municipal

authorities.

Meaning of the “Dustbin” Symbol

Protect our environment: do not dispose of

electrical equipment in the domestic waste.
Please return any electrical equipment that

you will no longer use to the collection points

provided for their disposal.

This helps avoid the potential effects of incorrect disposal

on the environment and human health.
This will contribute to the recycling and other forms of re-uti-

lisation of electrical and electronic equipment.
Information concerning where the equipment can be dis-

posed of can be obtained from your local authority.
