B  Connect the power adapter to the socket on the charging

station.

C  Connect the appliance holder with the floor nozzle. It

must engages. Take note of the contact pins on the floor

nozzle.

D  Fix the basic unit in the appliance holder. First place the

suction opening of the basic unit into the opening of the

appliance holder. Then push the handle of the basic unit

into the appliance holder. It must audibly engage.

E  When you want to charge the battery, hang the com-

pletely assembled appliance into the charging station.

Make sure of stability and correct assembly. The con-

tacts of the appliance holder must touch the contacts on

the charging station. The 4 contacts must be clean and

dry. Otherwise the battery will not be charged.

F  For space-saving storage, you can fold the handle of the

appliance holder. To do this, push the slider (13) upwards

and at the same time fold in the handle.

Charging the Battery

1.  Turn off the appliance.

2.  Connect the power adapter to a certified wall socket.

Charge the appliance for 4.5 hours before first-time use.

  NOTE:

•  The indicator lights show the state of charge of the

rechargeable battery.

•  Charging is completed when all 3 indicator lights

are lit.

•  It is normal for the appliance to heat up during

charging.

3.  Stop all other charging process after a maximum of 4.5

hours or once the indicator lights stay permanently on.

  CAUTION:

Always remove the mains plug from the power outlet after

charging is complete.

Using the Appliance

•  You can use the appliance as a floor vacuum cleaner or

as a handheld and upright vacuum cleaner (basic unit).

•  To separate the basic unit from the appliance holder,

press the button (18) and at the same time use the

handle to pull out the appliance.

•  Turn the appliance on or off with the on / off switch (5)

or (12).

•  During operation, you will be able to recognise the state

of charge of the rechargeable battery via the indicator

lights.

•  Use the   and   buttons to adjust the suction power.

•  Press the

 button to turn on the turbo brush on the

floor nozzle. The rotation is indicated via the lighting.

  NOTE:

The lighting can only be switched on or off while the

appliance is in operation.

Emptying the Collection Container

1.  Turn off the appliance.

2.  Keep the appliance horizontal when opening the collec-

tion container.

3.  Press the button (4) to unlock the collection container.

4.  Remove the two-piece filter insert.

5.  Turn and remove the coarse filter by slightly turning it

counterclockwise.

6.  Empty the components.

7.  Reinstall the components into the collection container in

reverse order.

8.

Attaching the collection container to the housing:

First position the collection container at the bottom of the

housing. Then lock it at the button (4) on the top.

Cleaning

  WARNING:

Under no circumstances should you immerse the motor housing

in water in order to clean it. Otherwise this might result in an elec-

tric shock or fire.

  CAUTION:

•  Do not use a wire brush or any abrasive items.

•  Do not use any acidic or abrasive detergents.

•  The single components are not dishwasher-safe.

•  Wipe the casing with a damp cloth.

•  You can wipe the power adapter unit with a dry cloth.
