adjusting suction power

You can adjust the suction power while vacuum cleaning.

  1

 Adjust the suction power by means of the electronic suction power knob (Fig. 17).

  2

 Turn the knob to MAX for maximum suction power (Fig. 18).

Use maximum suction power for vacuum cleaning ver y dir ty carpets and hard floors.

  3

 Turn the knob to MIN for minimum suction power.

Use minimum suction power for vacuum cleaning cur tains, table carpets, etc.

storage

  1

 Switch the appliance off and remove the mains plug from the wall socket.

  2

 Rewind the mains cord by pressing the cord rewind button (Fig. 19).

  3

 Put the appliance in upright position and attach the nozzle to the appliance by inserting the

ridge on the nozzle into the slot (Fig. 20).

replacing the dustbag

Replace the dustbag as soon as the dustbag-full indicator has changed colour permanently, i.e.

even when the nozzle is not placed on the floor (Fig. 21).

  1

 Switch the appliance off and open the cover (Fig. 22).

  2

 Push the dustbag holder backwards (Fig. 23).

  3

 Remove the full dustbag from the holder by pulling it up by the cardboard tag, which will

cause the dustbag to be sealed (Fig. 24).

  4

 Slide the cardboard front of the new dustbag into the two grooves of the dustbag holder.

Press it down as far as possible (Fig. 25).

  5

 Pull the dustbag holder forwards (‘click’) (Fig. 26).

You cannot close the cover if no dustbag has been inser ted.

ordering dustbags

Philips Classic s-bag

`

 paper dustbags are available under type number FC8021.

replacing filters

Motor Protection Filter

Replace the Motor Protection Filter once a year.

  1

 Switch the appliance off and open the cover. Remove the filter.

  2

 Insert a new filter into the holder with the white side pointing towards the dustbag

compartment (Fig. 27).

super Clean air Filter (specific types only)

Replace the Super Clean Air Filter ever y 6 months.

  1

 Open the grille at the back of the appliance and remove it (Fig. 28).

  2

 Remove the old filter and place the sides and the bottom edge of the new filter properly

behind the ridges of the holder on the inside of the grille.

-
