Motor Protection Filter

Replace the Motor Protection Filter once a year.

  1

 Open the cover and remove the filter.

 Insert a new filter into the holder with the white side pointing upwards (Fig. 15).

aFs Micro Filter

Replace the AFS Micro Filter ever y 6 months.

  1

 Open the grille (1) at the back of the appliance and remove it (2) (Fig. 16).

 Remove the old filter. Place the sides and the bottom edge of the new filter properly behind

the  ridges of the holder on the inside of the grille (Fig. 17).

 Reattach the grille to the vacuum cleaner. First hook the bottom edge of the grille into the

appliance (1) and then push the grille towards the appliance until it snaps home (2) (Fig. 18).

Two AFS Micro Filters and one Motor Protection Filter are available under type number FC8032.

Environment

Do not throw away the appliance with the normal household waste at the end of its life, but

hand it in at an official collection point for recycling. By doing this, you help to preser ve the

environment (Fig. 19).

guarantee and service

If you need information or if you have a problem, please visit the Philips website at

www.philips.com

or contact the Philips Customer Care Centre in your country (you find its phone number in the

worldwide guarantee leaflet). If there is no Customer Care Centre in your country, go to your local

Philips dealer or contact the Service Depar tment of Philips Domestic appliances and Personal Care BV.

troubleshooting

1  The suction power is insufficient.

Make sure the suction power knob is in maximum position (specific types only).

Make sure the slide on the handgrip is closed.

Perhaps the dustbag is full. Replace the dustbag.

Perhaps the filters are dir ty. Replace the filters.

The nozzle, tube or hose may be blocked up. To remove the obstruction, disconnect the

blocked-up item and connect it (as far as possible) the other way around. Switch on the vacuum

cleaner to force the air through the blocked-up item in opposite direction (Fig. 20).

-

-

-

-

-

-
