using the appliance

Vacuuming

  1

 Pull the cord out of the appliance and put the mains plug in the wall socket.

 Push the on/off button on top of the appliance with your foot to switch on the appliance.

You can carr y the vacuum cleaner by the handle at the front of the appliance.

adjusting suction power

You can adjust the suction power by means of:

the slide on the handgrip, or (Fig. 7)

the suction power knob (specific types only) (Fig. 8).

storage

  1

 Switch off appliance and remove the mains plug from the wall socket.

 Press the cord rewind button to rewind the mains cord.

 Put the appliance in upright position and attach the lower tube to the appliance by means of

the clip (Fig. 9).

Replacement

replacing the dustbag

Replace the dustbag as soon as the dustbag-full indicator has changed colour permanently.

Always unplug the appliance before you replace the dustbag.

  1

 Open the dustbag compartment cover (Fig. 10).

 Push the dustbag holder backwards (Fig. 11).

 Pull the cardboard tag upwards to remove the full dustbag from the holder. The dustbag is

sealed automatically (Fig. 12).

  4

 Slide the cardboard front of the new dustbag into the two grooves of the dustbag holder.

Press it down as far as possible (Fig. 1).

  5

 Pull the dustbag holder forwards (‘click’) and close the dustbag compartment cover.  (Fig. 14)

Note: If you have not inserted a dustbag, you cannot close the dustbag compartment cover.

Philips s-bag

`

 paper dustbags are available under type number FC8021 .

reusable dustbag

If provided, you can use the reusable dustbag instead of paper dustbags. The reusable dustbag can be

used and emptied repeatedly.

To remove and inser t the reusable dustbag, simply follow the instructions for replacing paper

dustbags.

To empty the reusable dustbag:

  1

 Remove the clip by sliding it off the dustbag sideways.

 Shake out the contents into a dustbin.

 Close the dustbag by sliding the clip back onto the bottom edge of the dustbag.

Philips reusable dustbags are available under type number 4341 004 92090.

replacing filters

Always unplug the appliance before you replace the filters.

-

-

-
