Assemble metal tube and handheld vacuum

First, assemble floorhead and metal tube according to
the method of assembling electric floor head and metal
tube.(Fig 4)

Assemble the floorhead, metal tube and

handheld vacuum cleaner

As shown by the arrow, align the conductive needle of
the metal tube with the coupler of the suction nozzle,
push up until a“click” sound is heard.(Fig5)

Assemble the charging holder

Assemble sequence:(Fig6)

1.Put the assembled vaccum cleaner into charging
holder, and align the vacuum cleaner to the wall.
Fix position of the charging holder, make sure that
floorhead does not touch ground.
2.Take off the vacuum cleaner, place the wall protecting
film(packed with user manual) on the wall and drill
holes, insert expansion pipe.

①

3.Put charging holder on the expansion pipe position,
lock in screw as

②

. The assembled charging holder is

like Fig

③

.

Assembly of accessories

For the convenience of use, this product is specially
equipped with some accessories for the handheld part
of the vacuum cleaner. When you use the handheld
vacuum cleaner alone, you can directly connect the
accessories according to your needs.

Assemble accessories to handheld vacuum

cleaner

Align electric mattress head connector with handheld
vacuum, insert to the end as the picture.(Fig 7)
Attn:The handheld vacuum can be connected with 2-in-
1 upholstery and 2-in-1 crevice tool as electric mattress
head.

4

5

6

7

①

②

③
