3

*Certain Models Only          ** Certain models only, nozzles may vary according to model

Cleaning the dust bin / separation unit

This cleaner uses a separation system unique to Hoover. If necessary the separation unit

can be disassembled from the dust bin and cleaned.

1.  Press the dust bin lid release button and remove the dust bin assembly from the

cleaner.

 [11]

2.  Hold the dust bin with one hand and with the other hand press the dust bin lid release

button to open the dust bin lid.

 [12]

3.  Remove the Vortex Finder (Red)  from the cyclone body.

 [13]

4.

Remove the cyclone body from the dust bin.

[14]

5.  If necessary, use a cloth to remove excessive dust from the red vortex finder and the

cyclone body surface.

[13]

6.  Place the dust bin under the tap.

[18]

Rinse with lukewarm water. Wash internal

surfaces of the dust bin with water only. DO NOT use soap detergents to wash the

internals of the dust bin.

7.  Reassemble the internal component to the dust bin, ensuring all components are dry.

8.  Close over the dust bin lid and refit dust bin assembly to cleaner.

Removing a blockage

1.  Check if the dust bin is full. If so refer to ‘Emptying the dust bin.

2.  If the dust bin is empty but suction is still low:

A. Do the filters need cleaning? If so refer to ‘Cleaning the washable filters’.

B. Check if there is any other blockage in the system - Use a rod or pole to remove any

blockage from the extension tube or flexible hose.

C. Check if pre-motor filter is fitted.

D. Check if the separation unit needs to be cleaned. Refer to ‘Cleaning the separation

unit.

USER CHECK LIST

CLEANER MAINTENANCE

Emptying the Dust Bin

When the dust reaches the max level indicator in the bin, empty the dust bin.

IMPORTANT:

 To maintain optimum performance do not allow the dust above the max level

indicator.

1.  Turn off the cleaner with the main switch and unplug the power cable.

2.  Press the dust bin lid release button and remove the dust bin assembly from the

cleaner.

 [11]

3.  Hold the dust bin with one hand and press the dust bin flap release trigger.

 [14]

4.  Close the dust bin flap and refit to the cleaner main body.

Cleaning the washable filters

The  cleaner  is  fitted  with  a  blue  filter  pack.  To  maintain  optimum  cleaning  performance

regularly remove the filters and tap against the side of the bin to release dust. The filters

should be washed every 5 bin empties or when the filter has excessive dust level.

IMPORTANT:

All  bagless  cleaners  require  regular  filter  cleaning.  Failure  to  clean  your

filters may result in air blockage, overheating and product failure. This may invalidate your

guarantee.

IMPORTANT:

 Regularly check and maintain the filters.

IMPORTANT:

Always ensure the filter pack is fully dry before use.

To access the filter:

1.  Press the dust bin lid release button and remove the dust bin assembly from the

cleaner.

[11]

2.  Hold the dust bin with one hand and with the other hand press the dust bin lid release

button to open the bin lid.

 [12]

3.  Remove the pre-motor filter located in the bin lid.

 [15]

4.  Gently tap and wash the pre-motor filter. Do not use hot water or detergents. Remove

excess water from the filter and leave to dry fully before re-using.

[18,19]

5.  Reassemble the pre-motor filter to the dust bin lid once fully dry and refit to the cleaner.

IMPORTANT:

Do not use the product without the filter pack fitted.

To access the exhaust filter:

1.  Unlock the exhaust filter door by pressing two buttons and pulling outward from main

cleaner.

[16]

2.  Remove the filter pack from recess by pulling the ring-pull of exhaust filter.

 [17]

3.  Gently tap and wash the filter unit. Do not use hot water or detergents. Remove excess

water from the filter and leave to dry fully before using.

[18,19]

4.  Reassemble  the  Filter  pack  once  it  is  fully  dry  and  refit  to  the  cleaner  by  inserting  it

back into the location and pushing it fully home.

5.  Lock the exhaust filter cover by pressing the edge which has the clips, you will hear a

click once the exhaust filter door fits into place.

IMPORTANT:

Do not use the product without the filter pack fitted.

GB

USER CHECKLIST

Should you have a problem with the product, complete this simple user checklist before

calling your local Hoover service.

• Is there a working electricity supply to the cleaner? Please check with another electrical

appliance.

• Is the dust bin over-filled? Please refer to ‘Cleaner Maintenance’.
• Is the filter blocked? Please refer to ‘Cleaner Maintenance’.
• Is the hose or nozzle blocked? Please refer to ‘Removing a blockage from the system’.
• Has the cleaner overheated? If so, it will take approximately 30 minutes to automatically

reset.
