Switching off and Winding up the Mains Lead

1.

Turn the vacuum cleaner off by the on / off switch and

remove the plug from the socket.

2.  Hold the cable to avoid wrapping.

3.  Press the cable winding button and guide the cable.

Maintenance

Emptying the dust collector

Empty the dust collector once the collected dirt reaches the

MAX marking.
1.  Disconnect the mains plug from the wall socket.

2.

Press the button (7) to release the dust collector. Remove

the dust collector.

3.  Empty the dust collector over a dustbin. In order to do so,

press the button on the dust collector to open the base

plate. (Page 4, Fig. B)

4.  Then close the base plate again.

5.  Attach the dust collector to the appliance. First position it

at the bottom of the appliance and then secure it with the

hook on top.

6.  Check that the position of the dust collector is secure by

briefly lifting the appliance at its carrying handle.

The Filter System

Your appliance features 4 filters. The common dust bag

system has been replaced by a transparent dust collector.

The higher flow speed of the collector allows for heavy dirt

and smallest floating particles to be separated from the

“sucked-in air”.
It is thus not necessary to buy dust bags.

The filters must be cleaned periodically.

The filter unit (Page 4, Fig. C to H)

The filter unit is composed of:

•

Nylon filter

•

Filter fleece

•

Central filter

•

Pre-filter

•  Fastening disk

 CAUTION:

•  Never wash the components in a washing machine or a

dishwasher!

•  Do not use a hairdryer for drying.

•  Operate the appliance again only when all components

are completely dry and have been installed correctly.

Proceed as follows to clean the filter unit:

1.  Empty the dust container as described above. (Steps

1 - 3)

2.

Disassembly of the filter unit

2.1.  Turn the filter unit in the

 direction. (Fig. C)

2.2.  Pull the filter unit from the dust container. (Fig. D)

2.3.  Turn the fastening disk and pull it off. (Fig. E)

2.4.  Pull the pre-filter from the central filter. (Fig. F)

2.5.  Open the cover of the filter unit. (Fig. G)

2.6.  Remove the nylon filter and the filter fleece. (Fig. H)

3.

Clean all parts of the filter unit and the dust container

under running water. You may use a soft brush.

4.  Allow all parts to dry completely in air.

5.

Assembly of the filter unit

5.1.  Insert the filter fleece and then the nylon filter into

the cover.

5.2.  Close the cover. It must lock mechanically.

5.3.  Set the pre-filter to the central filter.

 NOTE:

The pre-filter has recesses of different sizes,

which match the tabs on the central filter.

5.4.  Set the fastening disk onto the pre-filter and tighten

it by turning.

5.5.  Replace the filter unit in the dust container: Set

the guide tab on the filter unit to the

 symbol.

Tighten the filter unit by turning it in the

 direction.

Outlet filter

The appliance is also equipped with an outlet filter.

It is located on the back of the appliance.
1.  Push the lock (10) down and remove the ventilation grill.

2.

Remove the filter insert and clean it as described above.

3.

Place the completely dry filter back into the ventilation

grille.

4.  Put the ventilation grille back on the appliance. Observe

the guide lugs. The ventilation grid must engage audibly.

Cleaning

 WARNING:

•  Before cleaning remove the mains lead from the socket.
