Never use without the filter. Check that the filter is inserted correctly!

•  Hair, clothing and body parts away from the vacuum nozzle during

use!

•  Keep the vacuum cleaner away from sources of heat like radiators,

ovens, etc.!

Overview of the Components

1  Air slide

2 Handle

3  Suction hose

4  Cover lock (dust container)

5  On / off switch

6  Carrying handle

7  Dust collector release button

8  Cable-winding button

9  Suction power control

10  Ventilation grill lock (outlet filter)

11  Positioning aid

12  Dust container

13  Dust collector base plate

14  Hose connection

15  Connection head of the vacuum hose

16  Carpet / hard floor selector

17  Floor nozzle (with hook (not shown))

18  Telescopic suction tube

19  Parquet brush

20  Combined brush / crevice nozzle

Start-up

•  Insert the connecting head of the suction hose into the

hose connection of the appliance. It must lock mechan-

ically.

•  To disconnect the hose again, press the button on the

connecting head.

•  Insert the vacuum tube into the handle if required.

•  You can use the sliding switch on the telescopic suction

tube to adjust the length individually. (Page 4, Fig. A)

•

Then assemble the floor nozzle and / or the accessories.

Nozzle Attachment

Floor nozzle (17)

You can clean smooth surfaces and carpets with the floor

nozzle.

Set the selector (16) according to condition of the floor:

For durable hard floors like laminate, tiles, PVC,

etc.

For carpet floors, rugs, etc. with high or low pile

Parquet brush (19)

For gentle cleaning of sensitive hard floors like parquet,

laminate, tiles, etc.

Combined brush / crevice nozzle (20)

For vacuuming upholstery, curtains and in corners and

crevices etc.

 NOTE:

“2-in-1” nozzle:

When this is folded together it can be used as a groove

nozzle. If you would like to use the brush nozzle, pull the

brush section in the direction of the arrow until it locks in

place.

To detach the nozzle attachments from the suction pipe, pull

them off by turning them slightly.

Using the Appliance

1.  Unwind the length of cable you require.

 CAUTION:

•  Pull out the cable up to the maximum length indicat-

ed with the yellow mark.

•  Never pull the cable out up to the red mark as the

cable winding can be damaged.

 NOTE:

If the red mark is visible, pull in the cable with the help

of the cable winding button back to the yellow mark.

2.  Insert the mains plug into a correctly installed power

socket.

3.

Turn the device on by the on / off switch by pressing down

the button.

4.

Set the “carpet / hard floor” selector, depending on the

floor covering.

5.  Set the suction power with the suction power controller.

6.  Vacuum at a steady speed. There is no need to exert

pressure.

 NOTE:

Pay attention to the range that can be covered with the

cable length!

Air Slide (1)

Open the air slide on the hose handle in order to regulate the

airflow or to clear any particles sticking to the nozzle.
