•  Do not suck up liquids!

•  Do not suck up hot ashes or pointed or sharp objects!

•  Do not use the device in damp rooms!

•  Never use without the filter. Check that the filter is inserted correctly!

•  Hair, clothing and body parts away from the vacuum nozzle during

use!

•  Keep the vacuum cleaner away from sources of heat like radiators,

ovens, etc.!

Overview of the Components

1  Telescopic suction tube

2  Lever for extending and retracting the brushes

3  Floor nozzle (with hook (not shown))

4  Hose connection

5  Connection head of the vacuum hose

6  Opener dust-bag compartment

7  Suction hose

8  Dust bag filling display

9  Cable-winding button

10  Carrying handle

11  On/off switch

Accessories not shown:

Groove and brush nozzle

Start-up

•  Insert the connecting head of the suction tube into the hose

connection of the device until it clicks into place mechani-

cally.

•  To detach the hose again, keep the buttons on the connect-

ing head pressed down and pull out the hose.

•  Insert the vacuum tube into the handle if required.

•  You can use the sliding switch on the telescopic suction

tube to adjust the length individually.

•  Then assemble the floor nozzle and/or the accessories.

Nozzle Attachment

Floor nozzle (3)

The floor nozzle is fitted with rollers for easier guiding.

You can clean smooth surfaces and carpets with the floor

nozzle.
•  Adjust the brushes outwards or inwards using the lever (2).
Best use of the appliance depends on the texture of the floor

covering. We recommend the following use:
•

 Use without brushes:

  For vacuuming floor coverings with a deep pile

•

 Use with brushes:

  For vacuuming smooth floors and carpets with a shallow

pile

Crevice and jointed nozzle

For vacuuming upholstery, curtains and in corners and crevices

etc.

 NOTE: “2-in-1” nozzle:

When this is folded together it can be used as a groove

nozzle. If you would like to use the brush nozzle, pull the

brush section in the direction of the arrow until it locks in

place.

To detach the nozzle attachments from the suction pipe, pull

them off by turning them slightly.

Using the Appliance

1.  Unwind the length of cable you require.

CAUTION:

•  Pull out the cable up to the maximum length indi-

cated with the yellow mark.

•  Never pull the cable out up to the red mark as the

cable winding can be damaged.

NOTE:

If the red mark is visible, pull in the cable with the help of

the cable winding button back to the yellow mark.

2.  Insert the mains plug into a correctly installed power socket.

3.  Turn the device on by the on/off switch by pressing down

the button.

4.  Set the “carpet/hard floor” switch, depending on the floor

covering.

5.  Vacuum at a steady speed. There is no need to exert pres-

sure.

NOTE:

Pay attention to the range that can be covered with the

cable length!
