10

en

When the work is done

Figure

Unplug the vacuum cleaner.
Tug the power cord briefly and let go. The cable then
rewinds automatically.

Figure

To store or transport the vacuum cleaner, use the storage
aid on the underside of the vacuum cleaner.
Stand the vacuum cleaner up on its end. Slide the catch
on the floor tool into the groove on the underside of the
appliance.

You have purchased a floor vacuum cleaner which can
vacuum up any type of dry dirt using the dust container or
dust bag.

We recommend that you use:
-  the dust container, in particular for your hobbies, e.g. to

vacuum up wood shavings, etc.

-  the dust bag principally for everyday household cleaning.

Using the dust container

!

Caution: The dust bag change indicator only works in
conjunction with a dust bag.

Figure

Set the power setting to maximum for the best results
when vacuuming.
We recommend that you reduce the setting only when
vacuuming very delicate materials.

Emptying the dust filter

To achieve an optimal result when vacuuming, the dust
container should be emptied each time the vacuum cleaner
is used.

Figure

Turn the dust compartment locking lever in the direction
of the arrow to open the dust compartment cover.

Figure

Remove the dust container from the appliance.

Figure

Release the two snap locks on the bottom flap in the
direction of the arrow, open the flap until it clicks into the
stop position and the container will then empty the dirt in
a downwards direction.

If the bottom flap is very dirty, (thick dirt) clean it before
closing, by vacuuming it with the crevice nozzle, for
example.

(You must fit the dust bag in the vacuum cleaner
when you do this - see Figure 27)

Close the bottom flap so that it can be heard snapping
into position.

22

21

20

19

18

17

Figure

Put the dust bag back into the vacuum cleaner and close
the dust bag compartment lid.

!

Caution: The inside of the dust container may
become scratched with use and start to look opaque.
This does not, however, affect the performance of the
vacuum cleaner in any way, i.e. it will continue to
function as normal.

Cleaning the permanent filters and micro

filters in the dust container

The filters must be cleaned:

After any operating malfunctions, i.e. after a blockage is
cleared.

At least every six months.

Figure

Press the fastener on the rear side of the container and
remove the micro filter from the bottom of the container.

Remove the permanent filter from the bottom plate of the
container.

Figure

Wash the micro- and permanent filters.
The filter must then be left to dry for at least 24 hours.

After cleaning, place the permanent filter on the bottom
plate of the container.
Put the micro filter onto the container and fix it in place
by pushing in the direction of the arrow. You will hear the
flap snap shut.

Blockages

Removing a blockage in the dust container.

Figure

Empty the container (see figure 22)

Loosen the blockage, e.g. with a screwdriver, and tap or
vacuum it out.

(You must fit a dust bag in the vacuum cleaner before
vacuuming it out - see Figure 27)

Close the bottom flap so that it can be heard snapping
into position.

!

Caution: The micro- and permanent filters must be
cleaned following any operating problem (see Figure
24 and 25).

26

25

24

23
