8

do not pour any flammable substances or substances
containing alcohol onto the filters (filter bag, motor
protective filter, exhaust filter, etc.).

Disposal information

Packaging

The packaging is designed to protect the vacuum
cleaner from being damaged during transportation. It
is made of environmentally friendly materials and can
be recycled.
Dispose of packaging that is no longer required at an
appropriate recycling point.

Used vacuum cleaners

Used vacuum cleaners still contain many valuable

materials. Therefore, please take your used vacuum
cleaner to your retailer or recycling centre to be
recycled. For current disposal methods, please
enquire at your retailer or your local council.

Disposal of filters and dust bags

Filters and dust bags are made from environmentally
friendly materials.
As long as they do not contain substances that are
not permitted to be disposed of in the household
rubbish, you can dispose of them with your normal
household rubbish.

!

Please note

The mains socket must be protected by at least a 16
amp fuse.
If a fuse should blow when you switch on the
appliance, this may be because other electrical
appliances which have a high current draw are
connected to the same power circuit.
To prevent the fuse from blowing, select the lowest
power setting before switching the appliance on, and
increase the power only once it
is running.

Before using for the first time

Figure

Push the handle onto the flexible tube and until it
engages.

Setting up

Figure
a)

Push the hose connector into the opening on the vacuum
cleaner until it engages.

b)

To remove the flexible hose, press the two lugs together
and pull the hose out.

Figure
a)

Connect the handle and the suction pipe together.

b)

Push the handle into the telescopic tube until it engages.
To release the connection, press the release button and
pull the handle out.

3*

2

1*

Figure
a)

Connect the floor tool and the suction pipe together.

b)

Insert the telescopic tube into the floor tool connector.

Figure
a)

Connect the suction pipes together.

b)

Disconnect the telescopic tube and adjust its length by
moving the adjusting button/sliding sleeve in the
direction of the arrow.

Figure

Attach the accessories holder to the multi-purpose
nozzle and clip it onto the suction pipe/telescopic tube.

Figure

Holding the power cord by the plug, pull out the required
length and plug it into the mains socket.

Figure

Press the on/off button in the direction of the arrow to
switch your vacuum cleaner on/off.

Figure

Adjust the suction by turning the on/off button in the
direction of the arrow.

Vacuuming

Figure

Adjusting the floor tool:

a)

Rugs and carpets

b)

Hard floors

Caution!

Floor tools are subject to a certain amount of wear,
depending on the type of hard floors you have
(e.g. rough, rustic tiles). Therefore, you must check
the underside of the floor tool at regular intervals.
Worn undersides of floor tools may have sharp edges
that can damage sensitive hard floors, such as parquet
or linoleum. The manufacturer does not accept any
responsibility for damage caused by worn floor tools.

Figure

Vacuuming using the accessories
(if required, connect them to the handle or the suction
pipe).

a)

Multi-purpose nozzle
For cleaning corners and crevices, as well as upholstered
furniture, curtains, etc.

b)

Crevice nozzle
For cleaning crevices and corners.

c)

Upholstery nozzle
For cleaning upholstered furniture, curtains, etc.

d)

Matress nozzle
For cleaning mattresses, upholstery, etc.

e)

Hard-floor brush
For cleaning hard floor coverings (tiles, parquet flooring,
etc.)

f)

Hard furnishings brush
For cleaning window frames, cabinets, mouldings, etc.

11*

10

9

8

7

6*

5*

4*

*Depending on equipment
