38

Blockages

Removing a blockage in the dust container.

Figure

䡲

Empty the container (see figure 20)

䡲

Loosen the blockage, e.g. with a screwdriver, and tap or
vacuum it out.

(You must fit a dust bag in the vacuum cleaner before
vacuuming it out - see Figure 25)

䡲

Close the bottom flap so that it can be heard snapping
into position.

!

Caution: The micro- and permanent filters must be
cleaned following any operating problem
(see Figure 22 and 23).

Using dust bags

If necessary, a dust bag may be used instead of the dust
collector.

Figure

䡲

Open the vacuum cleaner lid (see Figure 18)

䡲

Remove the dust collector and insert a dust bag.

䡲

Close the vacuum cleaner lid.

You have bought an extremely powerful device.
The highest suction setting is therefore only recommended
for heavily soiled, short-pile carpets and hard floors.

The required suction power can be selected by adjusting
the suction regulator (see Figure 9).

䡲

Low suction range:
For vacuuming delicate fabrics, e.g. curtains.

䡲

Middle suction range:
For daily vacuuming of lightly soiled floors.

䡲

High suction range:
For vacuuming durable floor coverings, hard floors and
for heavily soiled surfaces.

Replacing the dust bag

Figure

If the dust bag change indicator is completely yellow
when the floor tool is lifted from the floor and the highest
suction power is selected, the dust bag must be
changed, even though it may not yet be full. In this case
it is essential to change the dust bag due to the type of
material it contains.
The nozzle, suction pipe and flexible tube must not be
blocked, as this would also lead to dust bag change
indicator being triggered.

!

Attention: The dust bag change indicator only
functions correctly in conjunction with a dust bag.

Figure

Open the lid by moving the locking lever in the direction
of the arrow.

27

26*

25

24

Figure

Seal the dust bag by pulling the locking tab and then
remove it.

Figure

Place a new dust bag in the holder and close the vacuum
cleaner lid.

!

Caution: The dust bag compartment lid will only close
when the dust bag, textile filter or dust collector are
inserted.

Cleaning the motor protection filter

The motor protection filter should be cleaned regularly by
knocking out the dirt and rinsing.

Figure

䡲

Open the dust bag compartment lid (see Figure 18).

䡲

Pull out the motor protection filter in the direction of the
arrow.

䡲

Clean the motor protection filter by tapping it.

䡲

If it is very dirty, the motor protection filter

should be rinsed.

The filter must then be left to dry for at least 24 hours.

䡲

After cleaning, slide the motor protection filter into the
vacuum cleaner and close the dust bag compartment lid.

Care

Always switch off the vacuum cleaner and disconnect the
power cord from the mains before cleaning the appliance.
The vacuum cleaner and plastic accessories can be cleaned
with a commercial plastic cleaner.

!

Do not use a scourer, glass-cleaning agent or
multipurpose cleaning product.
Never immerse the vacuum cleaner in water.

If necessary, the dust compartment can be cleaned with a
second vacuum cleaner or simply wiped with a dry cloth or
dusting brush.

Subject to technical modifications.

30*

29

28
