36

Replacement parts and accessories

A

Replacement filter pack

Filter type G (BBZ41FG)
For best performance: Gplus (BBZ41GPLUS)

Contents:
4 filter bags with seal
1 micro-hygiene filter

http://

www.dust-bag-bosch.com

B Textile filter (long-term filter)

BBZ10TFG

Reusable filter with Velcro fastening.

C TURBO-UNIVERSAL

®

-upholstery brush

BBZ42TB

Simultaneously brush and vacuum upholstered furniture,
mattresses, car seats, etc..
Particularly suitable for vacuuming animal hair and fur.
The brush roller is driven by the suction force of the
vacuum cleaner.
No electrical connection required.

D TURBO-UNIVERSAL

®

- floor brush

BBZ102TBB

Simultaneously brush and vacuum short-pile carpets
and fitted carpets or any kind of covers. Particularly
suitable for vacuuming animal hair and fur. The brush
roller is driven by the suction force of the vacuum
cleaner.
No electrical connection required.

E Hard floor nozzle

BBZ123HD

To vacuum smooth flooring (parquet, tiles, terracotta...).

Before using for the first time

Figure

Push the handle onto the flexible tube and until it
engages.

Setting up

Figure
a)

Push the hose connector into the opening on the vacuum
cleaner until it engages.

b)

To remove the flexible hose, press the two lugs together
and pull the hose out.

Figure
a)

Connect the handle and the suction pipe together.

b)

Push the handle into the telescopic tube until it engages.
To release the connection, press the release button and
pull the handle out.

Figure
a)

Connect the floor tool and the suction pipe together.

b)

Insert the telescopic tube into the floor tool connector.

Figure
a)

Connect the suction pipes together.

b)

Disconnect the telescopic tube and adjust its length by
moving the adjusting button/sliding sleeve in the
direction of the arrow.

5*

4*

3*

2

1*

Figure

Attach the accessories holder to the multi-purpose
nozzle and clip it onto the suction pipe/telescopic tube.

Figure

Holding the power cord by the plug, pull out the required
length and plug it into the mains socket.

Figure

Press the on/off button in the direction of the arrow to
switch your vacuum cleaner on/off.

Figure

Adjust the suction by turning the on/off button in the
direction of the arrow.

Vacuuming

Figure

Adjusting the floor tool:

a)

Rugs and carpets

b)

Hard floors

Caution!

Floor tools are subject to a certain amount of wear,
depending on the type of hard floors you have
(e.g. rough, rustic tiles). Therefore, you must check
the underside of the floor tool at regular intervals.
Worn undersides of floor tools may have sharp edges
that can damage sensitive hard floors, such as parquet
or linoleum. The manufacturer does not accept any
responsibility for damage caused by worn floor tools.

Figure

Vacuuming using the accessories
(if required, connect them to the handle or the suction
pipe).

a)

Multi-purpose nozzle
For cleaning corners and crevices, as well as upholstered
furniture, curtains, etc.

b)

Crevice nozzle
For cleaning crevices and corners.

c)

Upholstery nozzle
For cleaning upholstered furniture, curtains, etc.

d)

Matress nozzle
For cleaning mattresses, upholstery, etc.

e)

Hard-floor brush
For cleaning hard floor coverings (tiles, parquet flooring,
etc.)

f)

Hard furnishings brush
For cleaning window frames, cabinets, mouldings, etc.

11*

10

9

8

7

6*
