Set the adjustable floor tool:

Rugs and carpets

=>

Hard floors

=>

If you are vacuuming up relatively large particles, make
sure that you vacuum them up successively and
carefully to ensure that the vacuum channel of the floor
tool does not become blocked. If necessary, you should
raise the nozzle in order to better vacuum up the dirt
particles.

Figure

Vacuuming with accessories

Attach the nozzles to the suction pipe or hand grip as
required:

a)

Crevice nozzle for vacuuming crevices and corners,
etc.

b)

Upholstery nozzle for vacuuming upholstered
furniture, curtains, etc.

Toy trap*

The toy trap can prevent small parts from being
vacuumed into the dust bag.

Figure
a)

Remove the handle from the telescopic tube. Fit the
toy trap between the handle and the suction pipe.

b)

Turning the wheel anti-clockwise as far as possible
activates the collection function – small parts are
retained in the collection container.
Turning the wheel clockwise deactivates the
collection function.

c)

To remove the small parts that have been collected,
unlock the front window and fold it down.

●

Once you have removed the small parts, close and
lock the front window (you should hear it click into
place).

●

If necessary, any dirt that has collected can easily be
vacuumed off using the handle.

●

Remove the toy trap after use.

!

Please note:

The toy trap is not intended for continuous use and
should only be fitted when necessary.

Drill dust nozzle*

Figure
a)

Secure the drill dust nozzle to the handle and then
place against the wall, so that the nozzle drill hole
opening sits directly over the hole to be drilled.

b)

Select the lowest power setting and then switch on
the vacuum cleaner.
Suction holds the drill dust nozzle in the required
position.

c)

Depending on the surface of the wall to be drilled it
may be necessary to readjust the power to a higher
setting to ensure the drill dust nozzle is firmly
attached.
Any fine particles are automatically vacuumed up.

13*

14*

12

15*

52

Figure

You can use the parking aid on the back of the vacuum
cleaner if you wish to stop vacuuming for a short time.

●

Once you have switched off the appliance, slide the
hook on the floor tool into the recess on the rear of
the appliance.

Figure

To overcome obstacles, e.g. steps, the appliance can
also be carried by the handle on the appliance body.

When the work is done

Figure
a)

Pull out the mains plug.

b)

Briefly pull on the power cord and then release it (the
power cord retracts automatically).

Figure

To store/transport the appliance, you can use the
storage aid on the underside of the appliance.

a)

Stand the appliance upright on its end.

b)

Slide the hook on the floor tool into the recess on the
underside of the appliance.

Changing the filter

!

Please note:

Always switch off the appliance before

changing the filter.

Replacing the dust bag

Figure

●

If the dust bag change indicator in the lid is filled
completely when the floor tool is lifted from the floor
with the highest suction level selected, the dust bag
must be changed, even though it may not yet be full.
Even if the dust bag is not full, it may still need
changing, due to the type of dust which has been
vacuumed. First check that the nozzle, suction pipe
and flexible hose are not blocked, as this would also
lead to the dust bag change indicator being triggered.

●

The hand grip can easily be detached from the hose
to remove blockages.

Figure

Opening the lid

a)

Unlock the lid by pulling on the locking lever in the
direction of the arrow.

b)

Open the lid in the direction of the arrow.

Figure
a)

Close the dust bag by pulling on the locking tab.

b)

Take out the dust bag.

c)

Insert a new dust bag.

d)

Push the dust bag fully into the holder.

!

Please note:

the lid will only close if a dust bag has

been inserted.

Cleaning the motor protection filter

The motor protection filter should be cleaned regularly
by knocking out the dirt and rinsing.

16

17

18

19

20*

21

22

*depending on model
