Replacement parts and special

accessories

A Replacement filter pack

To get the most out of your appliance, we recom-
mend using PowerProtect genuine replacement bags
Type G ALL.
Contents:  4 dust bags with seal
We therefore recommend that you only use our origi-
nal dust bags.
Your appliance is a highly efficient vacuum cleaner
that achieves excellent cleaning results when used
with high-quality dust bags. Only by using high-quali-
ty dust bags (such as Bosch original dust bags) can
you ensure that your vacuum cleaner is working at
the energy efficiency class, dust pick-up rate and
dust retention capacity listed on its EU energy label.
The use of inferior-quality dust bags (e.g. paper
bags) can have a negative effect on the service life
and performance of your appliance. Using unsuitable
or inferior-quality dust bags can also damage your
vacuum cleaner. Such damage is not covered by our
guarantee.
You can find more information about this at
www.bosch-home.com/dust-bag. You can order our
original vacuum cleaner bags here.

B Hard floor brush

BBZ123HD

For vacuuming hard floors
(parquet, tiles, terracotta, etc.)

Initial use

Figure

●

Push the hand grip onto the flexible hose and lock it
in place.

Figure
a)

Push the flexible hose adapter into the air intake
opening in the vacuum cleaner lid until it locks in
place.

b)

To remove the flexible hose, press the two catches
together and pull out the hose.

Figure
a)

Push the hand grip into the telescopic tube. To
remove it, turn the hand grip slightly and pull it out of
the tube.

b)

Push the hand grip into the telescopic tube until it

engages.To release the connection, squeeze the
collar sleeve and pull the handle out.

Figure
a)

Insert the telescopic tube into the connecting piece
of the floor tool. To release the connection, turn the
tube slightly and pull it out of the floor tool.

b)

Push the telescopic tube into the connecting piece of
the floor tool until it locks in place. To release the
connection, press on the locking collar and pull out
the telescopic tube.

1

2

3*

4*

Figure

●

Move the adjusting sleeve/slider button in the direc-
tion of the arrow to unlock the telescopic tube and
adjust it to the length required.

Figure

●

Attach the accessories holder to the multi-purpose
nozzle and clip it onto the suction pipe/telescopic
tube.

Figure

●

Place the accessories holder in the required position
on the telescopic tube.

●

Use some pressure to insert the upholstery nozzle
and the crevice nozzle into the accessories holder
from above or below.

Figure

Holding the power cord by the plug, pull out to the
required length and insert the plug into the mains
socket.

Figure

Switching on and off

●

Press the ON/OFF button in the direction of the
arrow to switch your vacuum cleaner on.

Figure

Controlling the suction level

The suction level can be infinitely adjusted to the level
required by turning the control knob in the direction of
the arrow.

Low power range

=>

For vacuuming delicate materials,e.g.
upholstery, curtains, etc.
Medium power range

=>

For the daily vacuuming of light
dirt deposits.

High power range

=>

For vacuuming durable floor coverings,
hard floors and heavily soiled surfaces.

Figure

Telescopic tube with sliding switch and

auxiliary air control switch

The suction power can also be adjusted by turning the
auxiliary air control switch in the direction of the arrow.

Auxiliary air control switch open
=> suction power reduced
Auxiliary air control switch closed
=> maximum suction power

Vacuuming

!

Please note:

Floor tools are subject to a certain amount of wear,
depending on the type of hard floor you have (e.g.
rough, rustic tiles). Therefore, you must check the
underside of the floor tool at regular intervals. Worn
undersides of floor tools may have sharp edges that
can damage sensitive hard floors, such as parquet or
linoleum. The manufacturer does not accept any
responsibility for damage caused by worn floor tools.

8

6*

9

10

11*

5*

7*

*depending on model
