38

Replacement parts and special accesso-

ries

A  Dust bag
   To get the most out of your appliance, we recom-

mend using PowerProtect genuine replacement
bags (BBZ41FGALL).

 Contents:

     - 4 dust bags with fasteners
     - 1 micro-hygiene filter

!

  PLEASE NOTE
   Your appliance is a highly efficient vacuum cleaner

that can only achieve its best cleaning results using
genuine dust bags.

   Only if high-quality dust bags are used, such as ge-

nuine Bosch dust bags, can the figures specified on
the EU energy label pertaining to energy efficiency
class, suction and dust retention capacity be achie-
ved.

   Additionally, using inferior quality dust bags (e.g.

paper bags) can have a significant impact on the ser-
vice life and performance of your appliance.

Warranty claims can only be made if genuine Bosch
dust bags are used.

   For more information and to order genuine Bosch

dust bags, go to

   www.bosch-home.com/dust-bag

B  Washable microfilter
   Protects the motor of your vacuum cleaner, thus in-

creasing its ser vice life.

C  Hard-floor nozzle BBZ123HD
  For vacuuming hard floors
  (parquet, tiles, terracotta, etc.)

D  Hard-floor nozzle BBZ124HD
  Innovative "soft & roll" hard-floor nozzle:
  2 rotating brush rollers made from natural hair.
  Coarse dirt is not pushed away.

Before using your appliance for the first

time

Fig.

1

•

 Push the handle onto the flexible hose and lock it in
place.

Initial use

Fig.

2

a)  Push the flexible hose adapter into the air intake

opening in the lid until it locks in place.

b)  To remove the flexible hose, press the two catches

together and pull out the hose.

Fig.

3

•

 Push the handle into the telescopic tube until it
locks into place.

•

 To release the connection, press the locking collar
and pull out the telescopic tube.

Fig.

4

•

 Push the telescopic tube into the connecting piece
of the floor nozzle until it locks in place.

•

 To release the connection, press the locking collar
and pull out the telescopic tube.

Fig.

5*

•

Unlock the telescopic tube by moving the sliding
switch or adjusting sleeve in the direction of the ar-
row, and adjust to the desired length.

Fig.

6

a) Place the accessories holder in the required positi-

on on the telescopic tube.

b) Put the hard furnishings brush on the upholster y

nozzle and lock it in place.

c) Use some pressure to insert the upholster y nozzle

with hard furnishings brush and the crevice nozzle
into the accessories holder from above or below.

Fig.

7

•

Holding the power cord by the plug, pull it out to the
required length and insert the plug into the mains
socket.

!

  If using the appliance for longer than 30 minutes,

pull out the power cord completely.

=>

=  Risk of overheating and subsequent damage.

Fig.

8

 Switching on and off

•

To switch the vacuum cleaner on or off, press the
rotar y control.

Fig.

9

 Controlling the suction level

Turn the rotar y control to infinitely adjust the suction
level to the level required.
min  -   For vacuuming curtains and delicate textiles

-

For vacuuming upholstered furniture and
cushions

  -   For vacuuming delicate rugs und for daily vacu-

uming of lightly soiled floors

  -   For vacuuming durable floor coverings

max  -   For vacuuming hard floors and heavily soiled

rugs and carpets

Vacuuming

!

 Caution:

 Floor nozzles are subject to a certain amount of
wear, depending on the type of hard floors you have
(e.g. rough, rustic tiles). You must therefore check
the underside of the floor nozzle at regular inter vals.
Worn undersides of floor nozzles may have sharp
edges that can damage sensitive hard floors, such as
parquet or linoleum. The manufacturer does not ac-
cept any responsibility for damage caused by worn
floor nozzles.

* Depending on model
