Step 3. Tension adjustment of the door spring

    1. The door springs are set at the factory to the proper
tension for the outer door. If aesthetic wooden panel are
installed, you will have to adjust the door spring tension.
Rotate the adjusting screw to drive the adjustor to strain or
relax the steel cable.

    2. Door spring tension is correct when the door remains
horizontal in the fully opened position, yet rises to a close with
the slight lift of a finger.

Step 4. Cold water connection

Connect the cold water supply hose to a threaded

¾

 (inch) connector and make

sure that it is fastened tightly in place. If the water pipes are new or have not been
used for an extended period of time, let the water run to make sure that the water
is clear. This precaution is needed to avoid the risk of the water inlet to be blocked
and damage the appliance.

The safety supply hose consists of the double walls. The hose’s system
guarantees it is intervention by blocking the flow of water in case of the supply
hose breaking and when the air space between the supply hose itself and the
outer corrugated hose is full of water.

WARNING!

A hose that attaches to a sink spray can burst if it is installed on the same water

line as the dishwasher. If your sink has one, it is recommended that the hose be disconnected and
the hole plugged.

How to connect the safety supply hose

1. Pull The safety supply hoses completely out from storage compartment located at rear of

dishwasher.

2. Tighter the screws of the safety supply hose to the faucet with thread

¾

 inch.

3. Turn water fully on before starting the dishwasher.

How to connect the safety supply hose

1. Turn off the water.
2. Unscrew the safety supply hose from the faucet.

Step 5. Connection of drain hoses

Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into the sink,
making sure to avoid bending or crimping it. The height of drain pipe must be less than 1000 mm.
The free end of the hose must not be immersed in water to avoid the backflow of it.
