37

Cleaning And Maintenance Of The Oven’s Front Door Glass

Remove the profile by pressing the plastic latches on both left and right

sides  as  shown  in  figure  23  and  pulling  the  profile  towards  yourself  as
shown in figure 24. Then remove the inner-glass as shown in figure 25.
If required, middle glass can be removed in the same way. After cleaning
and maintenance are done, remount the glasses and the profile in reverse
order. Make sure the profile is properly seated in its place.

Catalytic Walls *

Catalytic walls are located on the left

and the right side of cavity under the
guides. Catalytic walls banish the bad
smell and obtain the best performance
from the cooker. Catalytic walls also
absorb oil residue and clean your oven
while it’s operating.

Removing the catalytic walls

In order to remove the catalytic walls; the guides must be pulled out.

As soon as the guides are pulled out, the catalytic walls will be released
automatically. The catalytic walls must be changed after 2-3 years.

Figure 23

Figure 24

Figure 25

1

2

Figure 26
