Instructions for the user

10.5 Removing the internal glass panels

The glass in the door should always be kept thoroughly clean. To facilitate cleaning, it is possible to
remove the door (see 10.3 Removing the door) and place it on a canvas, or open it and lock the hinges
in order to extract the glass panels. The glass panels of the door can be completely removed by following
the instructions provided below.

Warning: before removing the glass panels, make sure that at least one of the door's hinges has been
locked in the open position as described in chapter “10.3 Removing the door”. This operation may have
to be repeated during the glass removal process if the door is accidentally freed.

Removing the internal glass panel:

•  Remove the internal glass panel by pulling the rear part

gently upwards, following the movement indicated by the
arrows (1).

•  Detach the 4 pins attached to the glass panel from their slots

in the oven door by pulling the front part of the glass panel
upwards (2).

Removing the middle glass panels:

•  Remove the middle glass panel by lifting it upwards,

following the movement indicated by the arrows (1).

•  Pull the front of the glass panel upwards (2).

Cleaning:

Clean the external glass panel and the panels removed
previously. Use absorbent kitchen roll. In the case of stubborn
dirt, wash with a damp sponge and neutral detergent.

Replacing the glass panels:

•  Replace the panels in the opposite order to which they were

removed.

•  Take care to centre and inser t the 4 pins attached to the

internal glass panel into their slots in the oven door by
applying slight pressure.
