Support large panels to minimise the risk of blade
pinching and kickback.

 Large panels tend to sag

under their own weight. Supports must be placed
under the panel on both sides, near the line of cut and
near the edge of the panel.



Do not use dull or damaged blades.

 Unsharpened

or improperly set blades produce narrow kerf causing
excessive friction, blade binding and kickback.



Blade depth and bevel adjusting locking levers
must be tight and secure before making cut.

 If

blade adjustment shifts while cutting, it may cause
binding and kickback.



Use extra caution when making a "plunge cut" into
existing walls or other blind areas.

 The protruding

blade may cut objects that can cause kickback.

SAFETY INSTRUCTIONS FOR SAWS WITH LOWER
GUARD



Check lower guard for proper closing before each
use. Do not operate the saw if lower guard does
not move freely and close instantly. Never clamp
or tie the lower guard into the open position.

If saw

is accidentally dropped, lower guard may be bent.
Raise the lower guard with the retracting handle and
make sure it moves freely and does not touch the
blade or any other part, in all angles and depths of cut.



Check the operation of the lower guard spring.
If the guard and the spring are not operating
properly, they must be serviced before use.

 Lower

guard may operate sluggishly due to damaged parts,
gummy deposits, or a build-up of debris.



Lower guard should be retracted manually only
for special cuts such as “plunge cuts" and “
compound cuts". Raise lower guard by retracting
handle and as soon as blade enters the material,
the lower guard must be released.

For all other

sawing, the lower guard should operate automatically.



Always observe that the lower guard is covering
the blade before placing saw down on bench or
floor.

 An unprotected, coasting blade will cause the

saw to walk backwards, cutting whatever is in its path.
Be aware of the time it takes for the blade to stop after
switch is released.

SPECIFICATIONS

Voltage

230 V - 240 V   50 Hz

Input

1150 W

No-load speed

5600 RPM

Bore size

20 mm

Blade size

170 mm

Blade

Thickness 1.5

mm

Teeth

12 T

Width of cut

2.2 mm

Cutting capacity

at 0º

55 mm

at 45º

38 mm

Bevel scale

0 - 45º

STANDARD ACCESSORIES



Saw blade



Parallel fence



Wrench

ASSEMBLY

Be sure to disconnect the tool from the power supply
before attaching or removing the saw blade. Be sure that
the teeth of the saw blade are pointing upward at the front
of the tool

INTENDED USE

Sawing wood.
Don’t use it for a purpose not intended.

OPERATION

ATTACHING THE BLADE

See Figure 2-4.

1.

Press and hold the spindle lock button.

2.  Turn the hex-head bolt with a wrench until the spindle

locks.

3.

Loosen the hex-head bolt by turning the wrench
anticlockwise.

4.

Remove the hex-head bolt and the outer blade washer.

5.

Retract the lower guard back with the lower guard
lever as far as possible under the upper guard.

6.  Attach the saw blade against the inner blade washer

on the spindle.

7.  Fit the outer blade washer and the hex-head bolt.
8.

Tighten the hex-head bolt by turning the wrench
clockwise.

9.  After tightening the hex-head bolt, release the spindle

lock button.

NOTE:

 When the blade has been installed, make sure

the spindle lock has been released by spinning the blade
freely.
