DESCRIPTION

1. Spindle lock
2.  Bevel adjustment lever
3.  Edge guide lock screw
4. Base plate
5. Edge guide
6. Lower guard
7. Blade
8.  Lower guard lever
9. Upper guard
10. Outer blade

fl

 ange

11. Hex-head bolt
12. Wrench
13. Washer
14. Inner blade

fl

 ange

15. Depth adjustment lever
16. Depth of cut
17. Depth pointer
18. Depth scale
19. Bevel scale
20. Bevel pointer
21. Lock-off trigger
22. Switch
23. Live tool indicator
24. Vacuum adapter
25. 0

˚

 bevel notch

26. 45° bevel notch

SPECIAL SAFETY RULES

Do not use any abrasive wheels.

 DANGER

Keep hands away from cutting area. Keep hands
away from blade. Keep your second hand on
auxiliary handle, or motor housing.

 If both hands are

holding the saw, they cannot be cut by the blade.



Do not reach underneath the workpiece.

 The

guard cannot protect you from the blade below the
workpiece.



Adjust the cutting depth to the thickness of the
workpiece.

 Less than a full tooth of the blade teeth

should be visible below the workpiece.



Never hold piece being cut in your hands or
across your leg. Secure the workpiece to a stable
platform.

It is important to support the work properly

to minimize body exposure, blade binding, or loss of
control.



Hold power tool by insulated gripping surfaces
only, when performing an operation where the
cutting accessory may contact hidden wiring or its

own cord.

 Contact with a “live" wire will also make

exposed metal parts of the power tool “live" and shock
the operator.



When ripping always use a rip fence or straight
edge guide.

 This improves the accuracy of cut and

reduces the chance of blade binding.



Always use blades with correct size and shape
(diamond versus round) of arbour holes.

 Blades

that do not match the mounting hardware of the saw
will run eccentrically, causing loss of control. Use only
blades specified in this manual, complying with EN
847-1.



Never use damaged or incorrect blade washers
or bolt.

 The blade washers and bolt were specially

designed for your saw, for optimum performance and
safety of operation.

Causes and operator prevention of kickback:



kickback is a sudden reaction to a pinched, bound
or misaligned saw blade, causing an uncontrolled
saw to lift up and out of the workpiece toward the
operator;



when the blade is pinched or bound tightly by the
kerf closing down, the blade stalls and the motor
reaction drives the unit rapidly back toward the
operator;



if the blade becomes twisted or misaligned in the
cut, the teeth at the back edge of the blade can dig
into the top surface of the wood causing the blade
to climb out of the kerf and jump back toward the
operator.

Kickback is the result of saw misuse and/or incorrect
operating procedures or conditions and can be avoided by
taking proper precautions as given below.



Maintain a firm grip with both hands on the saw
and position your arms to resist kickback forces.
Position your body to either side of the blade, but
not in line with the blade.

 Kickback could cause the

saw to jump backwards, but kickback forces can be
controlled by the operator, if proper precautions are
taken.



When blade is binding, or when interrupting a cut
for any reason, release the trigger and hold the saw
motionless in the material until the blade comes
to a complete stop. Never attempt to remove the
saw from the work or pull the saw backward while
the blade is in motion or kickback may occur.

Investigate and take corrective actions to eliminate the
cause of blade binding.



When restarting a saw in the workpiece, centre
the saw blade in the kerf and check that saw teeth
are not engaged into the material.

 If saw blade is

binding, it may walk up or kickback from the workpiece
as the saw is restarted.
