ENGLISH

en

11

- Use an extraction unit and/or air purifiers.

- Ensure good ventilation of the workplace and

keep clean using a vacuum cleaner. Sweeping or

blowing stirs up dust.

- Vacuum or wash the protective clothing. Do not

blow, beat or brush.

See page 2.

(KS 55 FS is illustrated as an example.)

1 Screws (KS 55 FS only). With the screws

released, you can adjust the play and thus the

sliding movement of the guide rail by shifting the

screws. *

2 2 Locking screws (diagonal cuts)

3 Scale (diagonal cut angle)

4 Trigger

5 Locking  button

6 Scale  (depth  of  cut)

7 Locking screw (depth of cut)

8 Guide  plate

9 Extraction adapter

10 Lever (for swivelling back the movable guard)

11 Guideway for attachment to the Metabo guide

rail (KS 55 FS only) *

12 Undercut limit stop (increases the max.

diagonal cut angle from 45° to 47°)

13 Cutting indicator

14 Rip fence

15 Marking (for reading off the scale on the parallel

guide)

16 Locking screw (parallel guide)

17 Handle

18 Auxiliary handle

19 Depot for hexagon wrench

20 Spindle locking button

21 Saw blade fixing screw

22 Outer saw blade flange

23 Saw blade

24 Movable safety guard

25 Inner saw blade flange

Before plugging in the device, check that the

rated mains voltage and mains frequency, as

specified on the rating label, match your power

supply.

Australia: Always use a residual current device

(RCD) protected supply with a rated residual

current of 30 mA or less.

Pull the plug out of the plug socket before

carrying out any adjustments or servicing.

6.1 Setting depth of cut

Loosen the locking screw (7). Raise or lower the

motor section against the guide plate (8). Read the

depth of cut that has been set from the scale (6).

Tighten the locking  (7)screw again.

It is advisable to set the depth of cut so that no more

than half of each tooth on the saw blade juts out

under the workpiece. See illustration on page 2.

Note:

 the clamping power of the locking screw (7)

can be adjusted. Unscrew the screw on the lever to

do this. Remove lever and mount offset

counterclockwise. Secure with screw. When doing

this, note that the cutting depth setting device

moves freely when the lever is open.

6.2 Slanting saw blade for diagonal cuts

Loosen the locking screws (2). Tilt the motor section

against the guide plate.  (8) Read the angle which

has been set from the scale (3). Tighten the locking

(2)screws again.
For a diagonal cut angle of 47°, push down the

undercut limit stop  (12).

6.3 Sawdust extraction

Fit the extraction adapter (9) and secure with the

socket head screw.
To extract the sawdust, connect a suitable extrac-

tion unit with suction hose to the extraction adapter

(9).
If you are not using sawdust extraction, remove the

dust extraction adapter (9).

7.1 Switching ON and OFF

Switching on:

Press locking button (5) and hold in;

then actuate the trigger (4).

Switching off:

 Release the trigger (4).

7.2 Working instructions

Lay out the mains cable such that the cut can be

executed without obstruction.

Do not switch the machine on or off while the

saw blade is touching the workpiece.
Let the saw blade reach its full speed before

making a cut.

When the hand-held circular saw is added, the

movable guard is swung backwards by the work-

piece.

When sawing, never remove the machine

from the material with the saw blade turning.

Allow the saw blade to come to a standstill.

If the saw blade blocks, turn the machine off

immediately.

Sawing along a straight line:

the cutting indicator

is used here (13).
Sawing along a rail secured on the workpiece: In

order to achieve an exact cutting edge, you can

attach a rail to the workpiece and then guide the

hand-held circular saw along this rail by means of

the guide plate  (8).

Sawing with parallel stop:

For cuts parallel to a

straight edge.
The parallel guide (14) can be inserted from the

right-hand side into the support provided for it. Read

5. Overview

6. Initial Operation, Setting

7. Use
