ENGLISH

en

14

6.5 Extractor connection piece

Sawdust extraction

To extract the sawdust, connect a suitable

extraction unit with suction hose to the extraction

adapter (3).

7.1 The machine's multifunctional

monitoring system

If the machine switches off automatically, the

machine electronics have activated automatic

protection mode. A warning signal sounds

(continuous beeping). The beeping stops after a

maximum of 30 seconds or when the trigger switch

(5) is released.

In spite of this protective function, overloading

is still possible with certain applications and

can result in damage to the machine.

Causes and remedies:

1.

Battery pack almost flat

 (the electronics

prevent the battery pack from discharging totally

and avoid irreparable damage).

If one LED (20) is flashing, the battery pack is

almost flat. If necessary, press the button (21)

and check the LEDs (20) to see the charge level.

If the battery pack is almost flat, it must be

recharged.

2. Long continuous overloading of the machine will

activate the

temperature cut-out

.

The machine continues to run with reduced

performance until the temperature is back to

normal.
In case of excessive overheating, the machine

will switch off completely.
Leave the machine or battery pack to cool.
Note: If the battery pack feels very warm, the

pack will cool more quickly in your "AIR

COOLED" charger.
Note: The machine will cool more quickly if you

operate it at idling speed.

3. If the

current is too high

 (for example, if the

machine seizes continuously for long periods),

the machine switches off.

Switch off the machine at the trigger switch (5).

Then continue working as normal (in this case,

read in particular the safety instructions in

Chapter 4...Kickback... in addition to all other

safety instructions). Try to prevent the machine

from seizing.

7.2 Switching on and off

Switching on:

Push the locking button (6) forwards

and hold, then actuate the trigger (5) .

Switching off:

 Release the trigger switch (5).

7.3 Working Directions

Do not switch the machine on or off while the

saw blade is touching the workpiece.
Let the saw blade reach its full speed before

making a cut.

When the hand-held circular saw is added, the

movable guard is swung backwards by the

workpiece.

When sawing, never remove the machine

from the material with the saw blade turning.

Allow the saw blade to come to a standstill.

If the saw blade blocks, turn the machine off

immediately.

Sawing along a straight line:

the cutting indicator

is used here (11). The left notch (marked 0°)

indicates the direction of the cut if the saw blade is

held vertically. The right notch (marked 45°)

indicates the direction of the cut if the saw blade is

held at 45°.

Sawing along a rail secured on the workpiece:

In order to achieve an exact cutting edge, you can

attach a rail to the workpiece and then guide the

hand-held circular saw by means of the guide plate

along this rail.

Sawing with parallel guide:

For cuts parallel to a straight edge. The parallel

guide (12) can be inserted from either side into the

support provided for it. Tighten the locking screw

(10). It is best to calculate the exact cut width by

making a test cut.

Sawing with guide rail 6.31213:

For dead straight, tear-free cutting edges with

millimetre precision. The anti-slip coating keeps the

surface safe and protects the workpiece against

scratches. For guide rail 6.31213, see chapter on

Accessories.

Battery pack heat generation:

Under extremely hard application conditions (e.g.

sawing thick wooden planks), the heavy load can

cause the battery pack to heat (> 60 °C). To

conserve the battery pack, allow it to cool down

before continuing work.

Changing saw blades

Remove battery pack from machine.

Press in the spindle locking button (22) and hold in

place. Turn the saw spindle slowly with the spanner

in the saw blade fixing screw (23)  (18)until the lock

catches.
Unscrew the saw blade fixing screw in a clockwise

direction and remove the outer saw blade flange

(24). Pull back the movable guard (28) and remove

the saw blade.

Ensure that the inner saw blade flange (27) is

inserted in the right way: The inner saw blade

flange (27) has 2 sides, diameter 20 mm and 5/8“

(16 mm). Ensure a precise fit of saw blade mounting

hole to the inner saw blade flange  (27)! Incorrectly

installed saw blades do not run smoothly and lead

to loss of control.
Insert a new saw blade, Make sure the direction of

rotation is correct. The direction of rotation is

indicated by arrows on the saw blade and guard.

The contact areas between the inner saw blade

flange (27), the saw blade (25), the outer saw blade

7. Use

8. Maintenance
