17.

Never force the saw. Push the saw forward at a
speed so that the blade cuts without slowing.

Forcing the saw can cause uneven cuts, loss of
accuracy, and possible kickback.

Lower guard function

18.

Check lower guard for proper closing before
each use. Do not operate the saw if lower
guard does not move freely and close instantly.
Never clamp or tie the lower guard into the
open position.

 If saw is accidentally dropped,

lower guard may be bent. Raise the lower guard
with the retracting handle and make sure it moves
freely and does not touch the blade or any other
part, in all angles and depths of cut.

19.

Check the operation of the lower guard spring.
If the guard and the spring are not operating
properly, they must be serviced before use.

Lower guard may operate sluggishly due to
damaged parts, gummy deposits, or a build-up of
debris.

20.

Lower guard may be retracted manually only
for special cuts such as "plunge cuts" and
"compound cuts". Raise lower guard by
retracting handle and as soon as blade enters
the material, the lower guard must be released.

For all other sawing, the lower guard should
operate automatically.

21.

Always observe that the lower guard is
covering the blade before placing saw down on
bench or floor.

 An unprotected, coasting blade will

cause the saw to walk backwards, cutting whatever
is in its path. Be aware of the time it takes for the
blade to stop after switch is released.

22.

To check lower guard, open lower guard by
hand, then release and watch guard closure.
Also check to see that retracting handle does
not touch tool housing.

 Leaving blade exposed

is VERY DANGEROUS and can lead to serious
personal injury.

Additional safety warnings

23.

Use extra caution when cutting damp wood,
pressure treated lumber, or wood containing
knots.

 Maintain smooth advancement of tool

without decrease in blade speed to avoid
overheating the blade tips.

24.

Do not attempt to remove cut material when
blade is moving. Wait until blade stops before
grasping cut material.

Blades coast after turn off.

25.

Avoid cutting nails. Inspect for and remove all
nails from lumber before cutting.

26.

Place the wider portion of the saw base on
that part of the workpiece which is solidly
supported, not on the section that will fall off
when the cut is made. As examples, Fig. 1
illustrates the RIGHT way to cut off the end of
a board, and Fig. 2 the WRONG way. If the
workpiece is short or small, clamp it down. DO
NOT TRY TO HOLD SHORT PIECES BY HAND!

Fig. 1

000147

Fig. 2

000150

27.

Before setting the tool down after completing
a cut, be sure that the lower guard has closed
and the blade has come to a complete stop.

28.

Never attempt to saw with the circular saw
held upside down in a vise. This is extremely
dangerous and can lead to serious accidents.

000029

29.

Some material contains chemicals which may
be toxic. Take caution to prevent dust
inhalation and skin contact. Follow material
supplier safety data.

30.

Do not stop the blades by lateral pressure on
the saw blade.

31.

Always use blades recommended in this
manual. Do not use any abrasive wheels.

32.

Keep blade sharp and clean.

 Gum and wood

pitch hardened on blades slows saw and
increases potential for kickback. Keep blade clean
by first removing it from tool, then cleaning it with
