9 ENGLISH

WARNING:

NEVER defeat the lock-off button

by taping down or some other means.

 A switch with

a negated lock-off button may result in unintentional

operation and serious personal injury.

WARNING:

NEVER use the tool if it runs when

you simply pull the switch trigger without press-

ing the lock-off button.

 A switch in need of repair

may result in unintentional operation and serious

personal injury. Return tool to a Makita service center

for proper repairs BEFORE further usage.

NOTICE:

Do not pull the switch trigger hard

without pressing in the lock-off button.

 This can

cause switch breakage.

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and unplugged before carrying out

any work on the tool.

Removing or installing circular saw

blade

CAUTION:

Be sure the circular saw blade is

installed with teeth pointing up at the front of the tool.

CAUTION:

Use only the Makita wrench to

install or remove the circular saw blade.

To remove the circular saw blade, press the shaft lock

fully so that the circular saw blade cannot revolve and

use the wrench to loosen the hex bolt counterclockwise.

Then remove the hex bolt, ring (country specific), outer

flange and circular saw blade.

►

Fig.11:

1.

 Shaft lock

2.

 Hex wrench

For tool without the ring

►

Fig.12:

1.

 Hex bolt

2.

 Outer flange

3.

 Circular saw

blade

4.

 Inner flange

5.

 Spindle ring

For tool with the ring

►

Fig.13:

1.

 Hex bolt

2.

 Outer flange

3.

 Circular saw

blade

4.

 Ring

5.

 Inner flange

6.

 Spindle ring

To install the circular saw blade, follow the removal

procedure in reverse.

For tool with the inner flange for

other than 15.88 mm hole-diameter

saw blade

Mount the inner flange onto the mounting shaft so that

the protrusion on the inner flange faces outward and

then place saw blade and outer flange.

►

Fig.14:

1.

 Mounting shaft

2.

 Inner flange

3.

 Circular

saw blade

4.

 Outer flange

5.

 Hex bolt

WARNING:

BE SURE TO TIGHTEN THE HEX

BOLT CLOCKWISE SECURELY. Also be careful

not to tighten the bolt forcibly. Slipping your hand

from the hex wrench can cause a personal injury.

For tool with the inner flange for a

15.88 mm hole-diameter saw blade

(country specific)

Mount the inner flange with its recessed side facing

outward onto the mounting shaft and then place saw

blade (with the ring attached if needed), outer flange

and hex bolt.

For tool without the ring

►

Fig.15:

1.

 Mounting shaft

2.

 Inner flange

3.

 Circular

saw blade

4.

 Outer flange

5.

 Hex bolt

For tool with the ring

►

Fig.16:

1.

 Mounting shaft

2.

 Inner flange

3.

 Circular

saw blade

4.

 Outer flange

5.

 Hex bolt

6.

 Ring

WARNING:

BE SURE TO TIGHTEN THE HEX

BOLT CLOCKWISE SECURELY. Also be careful

not to tighten the bolt forcibly. Slipping your hand

from the hex wrench can cause a personal injury.

WARNING:

If the ring is needed to mount the

blade onto the spindle, always be sure that the

correct ring for the blade's arbor hole you intend

to use is installed between the inner and the outer

flanges.

 Use of the incorrect arbor hole ring may

result in the improper mounting of the blade causing

blade movement and severe vibration resulting in

possible loss of control during operation and in seri-

ous personal injury.

Blade guard cleaning

When changing the circular saw blade, make sure to

also clean the upper and lower blade guards of accu-

mulated sawdust as discussed in the Maintenance

section. Such efforts do not replace the need to check

lower guard operation before each use.

Hex wrench storage

When not in use, store the hex wrench as shown in the

figure to keep it from being lost.

►

Fig.17:

1.

 Hex wrench

Connecting a vacuum cleaner

Optional accessory

When you wish to perform clean cutting operation, connect a

Makita vacuum cleaner to your tool using the dust nozzle.

1.

If your circular saw has long lever (country spe-

cific), replace it with the short lever supplied with the

dust nozzle.

►

Fig.18:

1.

 Long lever (country specific)

2.

 Screw

3.

 Short lever

Do not use the dust nozzle with the long lever attached.

You will not be able to make a cut because the lower

guard movement is hindered by the dust nozzle.

2.

Install the dust nozzle on the tool using the screw.

►

Fig.19:

1.

 Dust nozzle

2.

 Screw

3.

Connect a hose of the vacuum cleaner to the dust

nozzle.

►

Fig.20
