Technical Data

Assembly

Mounting/Replacing the Saw Blade



Before any work on the machine itself, pull the mains
plug.



When mounting the saw blade, wear protective gloves.

Danger of injury when touching the saw blade.



Only use saw blades that correspond with the charac-
teristic data given in the operating instructions.



Do not under any circumstances use grinding discs as
the cutting tool.

Selecting a Saw Blade

An overview of recommended saw blades can be found at the
end of this manual.

Removal of the Saw Blade (see figure A)

For changing the cutting tool, it is best to place the machine
on the face side of the motor housing.

– Press the spindle lock button

5

 and keep it pressed.



The spindle lock button 5 may be actuated only when
the saw spindle is at a standstill.

Otherwise, the power

tool can be damaged.

– With  the  Hex  key

18

, unscrew the clamping bolt

19

 turning

in rotation direction



.

– Tilt back the retracting blade guard

12

 and hold firmly.

– Remove the clamping flange

20

 and the saw blade

21

 from

the saw spindle

23

.

Mounting the Saw Blade (see figure A)

For changing the cutting tool, it is best to place the machine
on the face side of the motor housing.

– Clean the saw blade

21

 and all clamping parts to be assem-

bled.

– Tilt back the retracting blade guard

12

 and hold firmly.

– Place  the  saw  blade

21

 on to the mounting flange

22

. The

cutting direction of the teeth (direction or arrow on saw
blade) and the direction-of-rotation arrow on the blade
guard

16

 must correspond.

– Mount  the  clamping  flange

20

 and screw in the clamping

bolt

19

 turning in rotation direction



. Observe correct

mounting position of mounting flange

22

 and clamping

flange

20

.

– Press the spindle lock button

5

 and keep it pressed.

– With  the  Hex  key

18

, tighten the clamping bolt

19

 turning

in rotation direction



. The tightening torque is between

6 – 9 Nm, which corresponds to hand tight plus ¼ turn.

Circular Saw

GKS 65

GKS 65 G

GKS 65 GCE

Article number

3 601 F67 0..

3 601 F68 9..

3 601 F68 9..

Rated power input

W

1 600

1 600

1 800

No-load speed

min

-1

5 900

5 900

2 300 – 5 000

Rotational speed under load, max.

min

-1

4 200

4 200

1 400 – 4 000

Cutting depth, max.

– for  0 °  bevel  angle
– for  45 °  bevel  angle

mm
mm

65
48

65
48

65
48

Spindle lock







Speed preselection

–

–



Constant electronic control

–

–



Temperature Dependent Overload Protection

–

–



Reduced starting current

–

–



Base plate dimensions

mm

170 x 305

203 x 327

203 x 327

Saw blade diameter, max.

mm

190

190

190

Saw blade diameter, min.

mm

184

184

184

Blade thickness, max.

mm

1.7

1.7

1.7

Tooth thickness/setting, max.

mm

2.6

2.6

2.6

Tooth thickness/setting, min.

mm

1.8

1.8

1.8

Mounting bore

mm

30

30

30

Weight according to EPTA-Procedure 01/2003

kg

4.8

5.1

5.2

Protection class

 /

II

 /

II

 /

II

The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.

Only for power tools without reduced starting current: Starting cycles generate brief voltage drops. Interference with other equipment/machines may
occur in case of unfavourable mains system conditions. Malfunctions are not to be expected for system impedances below 0.36 ohm.
