16

 | English

1 609 92A 2CZ | (14.7.16)

Bosch Power Tools



Use appropriate detectors to determine if utility lines
are hidden in the work area or call the local utility com-
pany for assistance.

Contact with electric lines can lead

to fire and electric shock. Damaging a gas line can lead to
explosion. Penetrating a water line causes property dam-
age.



Do not operate the power tool stationary.

It is not de-

signed for operation with a saw table.



Do not use high speed steel (HSS) saw blades.

Such saw

blades can easily break.



Do not saw ferrous metals.

Red hot chips can ignite the

dust extraction.



Secure the workpiece.

A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.



Always wait until the machine has come to a complete
stop before placing it down.

The tool insert can jam and

lead to loss of control over the power tool.



Do not open the battery.

Danger of short-circuiting.

Protect the battery against heat, e. g., against
continuous intense sunlight, fire, water, and
moisture.

Danger of explosion.



In case of damage and improper use of the battery, va-
pours may be emitted. Ventilate the area and seek
medical help in case of complaints.

The vapours can irri-

tate the respiratory system.



Use the battery only in conjunction with your Bosch
power tool.

This measure alone protects the battery

against dangerous overload.



The battery can be damaged by pointed objects such as
nails or screwdrivers or by force applied externally.

An

internal short circuit can occur and the battery can burn,
smoke, explode or overheat.

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for lengthways and crossways cut-
ting of wood with straight cutting lines as well as mitre cuts in
wood while resting firmly on the workpiece.

The light of this power tool is intended to illuminate the power
tool’s direct area of working operation and is not suitable for
household room illumination.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Battery pack

2

Battery unlocking button

3

Lock-off button for On/Off switch

4

On/Off switch

5

Hex key

6

Spindle lock button

7

Base plate

8

Fastening bolt for parallel guide

9

Scale for mitre angle

10

Wing bolt for bevel-angle preselection

11

Cutting mark, 45 °

12

Cutting mark, 0 °

13

Blade guard

14

Handle (insulated gripping surface)

15

Battery charge-control indicator

16

Temperature control/overload protection indicator

17

Wing bolt for cutting depth preselection

18

Cutting-depth scale

19

Lever for retracting blade guard

20

Saw spindle

21

Retracting blade guard

22

Mounting flange

23

Saw blade

24

Clamping flange

25

Clamping bolt

26

“PowerLight”

27

Reference mark for mitre angle setting

28

Fastening screw for extraction adapter

29

Extraction adapter *

30

Vacuum hose *

31

Reference mark for cutting depth setting

32

Parallel guide/guide rail adapter *

33

Set of screw clamps *

34

Guide rail *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Circular Saw

GKS 12V-26

Article number

3 601 FA1 0..

Rated voltage

V=

12

No-load speed

min

-1

1 400

Cutting depth, max.
– for  0 °  bevel  angle
– for  45 °  bevel  angle

mm
mm

26.5
17.0

* depending on the battery pack being used

** Limited performance at temperatures < 0 ° C
