English |

9

(1)

Spindle lock button

(2)

Protective guard with chip container

(3)

Utility hook

(4)

Cutting depth scale

(5)

Hex key

(6)

Lock-off function for on/off switch

(7)

On/off switch

(8)

Battery release button

a)

(9)

Battery

a)

(10)

Clamping lever for cutting depth preselection

(11)

Motor housing

(12)

0° cut mark

(13)

Base plate

(14)

Parallel guide

a)

(15)

Handle (insulated gripping surface)

(16)

Clamping bolt with washer

(17)

Clamping flange

(18)

Circular saw blade

a)

(19)

Mounting flange

(20)

Saw spindle

(21)

Retracting blade guard

(22)

Adjusting lever for retracting blade guard

(23)

Pair of screw clamps

a)

(24)

Lid of the chip container

(25)

Chip container locking mechanism

(26)

"PowerLight" lamp

a)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical data

Hand-held circular saw

GKM 18V-50

Article number

3 601 FB8 0..

Rated voltage

V

18

No-load speed

A)

min

-1

4250

Max. cutting depth

B)

– at a 0° mitre/bevel angle

mm

50

Spindle lock

●

Base plate dimensions

mm

105 x 200

Max. saw blade diameter

mm

136

Max. base blade thickness

mm

1.6

Min. base blade thickness

mm

1.0

Max. tooth thickness/offset

mm

2.5

Min. tooth thickness/offset

mm

1.2

Locating bore

mm

20

Weight according to
EPTA-Procedure 01:2014

kg

2.6–3.6

Hand-held circular saw

GKM 18V-50

Recommended ambient tem-
perature during charging

°C

0 to +35

Permitted ambient temperat-
ure during operation

C)

 and

during storage

°C

–20 to +50

Recommended rechargeable
batteries

GBA 18V...

ProCORE18V...

Recommended chargers

GAL 18...

GAX 18...

GAL 36...

A) Measured at 20–25 °C with rechargeable battery

GBA 18V

5.0Ah

.

B) If the ProCore 18V 12.0Ah battery is used, this sits on the work-

piece during working. Consequently, the maximum cutting
depth cannot be reached.

C) Limited performance at temperatures < 0 °C

Fitting

u

Only use saw blades the maximum permitted speed of
which is higher than the no-load speed of the power
tool.

Charging the Battery

u

Use only the chargers listed in the technical data.

 Only

these chargers are matched to the lithium-ion battery of
your power tool.

Note:

The battery is supplied partially charged. To ensure

full battery capacity, fully charge the battery in the charger
before using your power tool for the first time.
The lithium-ion battery can be charged at any time without
reducing its service life. Interrupting the charging process
does not damage the battery.
The lithium-ion battery is protected against deep discharge
by the "Electronic Cell Protection (ECP)". When the battery
is discharged, the power tool is switched off by means of a
protective circuit: The application tool no longer rotates.

u

Do not continue to press the On/Off switch after the
power tool has automatically switched off.

 The battery

can be damaged.

Follow the instructions on correct disposal.

Removing the battery

The battery

(9)

 is equipped with two locking levels to pre-

vent the battery from falling out if the battery release button

(8)

 is pressed unintentionally. As long as the battery is inser-

ted in the power tool, it is held in position by means of a
spring.
To remove the battery

(9)

, press the release button

(8)

 and

pull the battery to the rear and out of the power tool.

Do not

use force to do this.

Battery charge indicator

The green LEDs on the battery charge indicator indicate the
state of charge of the battery. For safety reasons, it is only
