and seek medical attention should you experience any ad-
verse effects. The vapours may irritate the respiratory
system.

u

Do not open the battery.

There is a risk of short-circuit-

ing.

u

The battery can be damaged by pointed objects such
as nails or screwdrivers or by force applied externally.

An internal short circuit may occur, causing the battery to
burn, smoke, explode or overheat.

u

Only use the battery with products from the manufac-
turer.

 This is the only way in which you can protect the

battery against dangerous overload.

Protect the battery against heat, e.g.
against continuous intense sunlight, fire,
water and moisture.

 There is a risk of explo-

sion.

u

Always wait until the power tool has come to a com-
plete stop before placing it down.

 The application tool

can jam and cause you to lose control of the power tool.

Product Description and
Specifications

Read all the safety and general instructions.

Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.

Please observe the illustrations at the beginning of this oper-
ating manual.

Intended use

The power tool is intended for making straight cuts in wood
with and against the grain and mitre cuts in wood while rest-
ing firmly against the workpiece.

Product features

The numbering of the product features refers to the diagram
of the power tool on the graphics page.

(1)

Battery

(2)

Battery release button

(3)

Lock-off button for on/off switch

(4)

On/off switch

(5)

Hex key

(6)

Spindle lock button

(7)

Base plate

(8)

Fastening screw for parallel guide

(9)

Scale for mitre/bevel angles

(10)

Wing bolt for mitre/bevel angle preselection

(11)

Cut mark 45°

(12)

Cut mark 0°

(13)

Protective guard

(14)

Handle (insulated gripping surface)

(15)

Battery charge indicator

(16)

Temperature monitoring/overload protection indic-
ator

(17)

Wing bolt for preselecting the cutting depth

(18)

Cutting depth scale

(19)

Adjusting lever for retracting blade guard

(20)

Saw spindle

(21)

Retracting blade guard

(22)

Mounting flange

(23)

Circular saw blade

(24)

Clamping flange

(25)

Clamping bolt

(26)

“PowerLight” lamp

(27)

Reference mark for mitre angle setting

(28)

Fastening screw for dust extraction adapter

A)

(29)

Dust extraction adapter

A)

(30)

Dust extraction hose

A)

(31)

Reference mark for cutting depth setting

(32)

Parallel guide/guide rail adapter

A)

(33)

Pair of screw clamps

A)

(34)

Guide rail

A)

A)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical data

Hand-held circular saw

GKS 12V-26

Article number

3 601 FA1 0..

Rated voltage

V

12

No-load speed

rpm

1400

Max. cutting depth

– at a 0° mitre/bevel angle

mm

26.5

– at a 45° mitre/bevel angle

mm

17.0

Spindle lock

●

Base plate dimensions

mm

167 x 88

Max. saw blade diameter

mm

85

Min. saw blade diameter

mm

85

Max. base blade thickness

mm

0.7

Max. tooth thickness/offset

mm

1.1

Min. tooth thickness/offset

mm

1.0

Locating bore

mm

15

Weight according to
EPTA-Procedure 01:2014

kg

1.3–1.6

A)

Permitted ambient temperature

– during charging

°C

0 to +45

– during operation

B)

 and

during storage

°C

-20 to +50

Recommended batteries

GBA 12V...

GBA 10.8V...
