ENGLISH

en

10

L = anti-clockwise rotation (for the removal of

screws)

0 = Centre  position:  with  the transporting safety

device engaged (switch-on lock)

7.5 Tool change with SDS chuck

Before fitting, clean tool shank and apply

special grease (accessories order no.

6.31800)! Use only SDS-Plus tools.

Inserting tools:

- Turn tool and insert until it engages. The tool is

locked automatically.

Removing the tool:

See page 2, fig. A.
- Pull tool lock (1) backwards in direction indicated

by arrow (a) and remove tool (b).

7.6 Metabo VibraTech (MVT)

For reduced vibrations and less stress on the

hands.
Always apply a moderate amount of pressure to the

handle when pushing down the machine and do not

force. Vibrations are reduced most effectively at the

central position (5).

-

Ventilation slits:

Clean the ventilation slits on the machine occa-

sionally.

- Remove the

battery pack

 periodically and wipe

the contact area of the battery pack and machine

with a dry cloth and remove drilling dust.

f

Metabo S-automatic safety stop:

 The LED light

(11) lights up and the machine SWITCHES OFF

automatically. If the speed is too high (if the

machine seizes suddenly), the machine switches

off. Switch off the machine at the trigger switch (7).

Switch it on again and continue to work as normal.

Try to prevent the machine from seizing.

f

Use only original Metabo or CAS (Cordless Alliance

System) battery packs and accessories.
Use only accessories that fulfil the requirements

and specifications listed in these operating instruc-

tions.
Fit accessories securely. If the machine is operated

in a holder: secure the machine well. Loss of control

can cause personal injury.

Batter chargers

: ASC 55, ASC 30-36, etc.

Battery packs with different capacities.

Only

use battery packs with voltage suitable for your

power tool.

Order no.:

625406000  ............... 12 V  2.0 Ah (LiPower)

625349000  ............... 12 V  4.0 Ah (LiHD)

etc.
625596000  ............... 18 V  2.0 Ah (LiPower)

625367000  ............... 18 V  4.0 Ah (LiHD)

etc.

For a complete range of accessories, see

www.metabo.com or the catalogue.

Repairs to electrical tools must be carried out by

qualified electricians ONLY!
If you have Metabo electrical tools that require

repairs, please contact your Metabo service centre.

For addresses see www.metabo.com.
You can download spare parts lists from

www.metabo.com.

Do not allow battery packs to come into contact with

water!

To protect the environment, do not dispose of

power tools or battery packs in household

waste. Observe national regulations on

separated collection and recycling of disused

machines, packaging and accessories.
Before disposal, discharge the battery pack in the

power tool. Prevent the contacts from short-circu-

iting (e. g. by protecting them with adhesive tape).

f

Explanation of details on page 3. Subject to

changes serving technical progress.

U

= Voltage of battery pack

n

0

= No-load speed

n

1

= Load speed

dia.

max

= Maximum drill diameter

s

max

= Maximum  impact  rate

W

= Single impact force

m

= Weight with smallest battery pack

D

= D=Collar diameter

Measured values determined in conformity with EN

60745.

 Direct current

The technical specifications quoted are subject to

tolerances (in compliance with the relevant valid

standards).

Emission values

Using these values, you can estimate the

emissions from this power tool and compare these

with the values emitted by other power tools. The

actual values may be higher or lower, depending on

the particular application and the condition of the

tool or power tool. In estimating the values, you

should also include work breaks and periods of low

use. Based on the estimated emission values,

specify protective measures for the user - for

example, any organisational steps that must be put

in place.

8. Maintenance, cleaning

9. Troubleshooting

10. Accessories

11. Repairs

12. Environmental Protection

13. Technical Specifications
