5

GB

English

T E C H N I C A L  DATA

Rotar y Hammer

KH 5 G

Production code

4181 61 03...

... 000001-999999

Rated input

1100 W

Output

550 W

No-load speed

450 min

-1

Speed under load max.

430 min

-1

Rate of percussion under load max.

3000 min

-1

Impact energy per stroke according to EPTA-Procedure 05/2009, Drilling / Chiselling

7,5 / 7,5 J

Impact energy per stroke (pre 2009), Drilling / Chiselling

9,0 / 9,0 J

Drilling capacity in concrete

 40 mm (SDS-max)

Tunnel bit in concrete, bricks and limestone

65 mm (SDS-max)

Core cutter in concrete, bricks and limestone

105 mm (SDS-max)

Chuck neck diameter

 66  mm

Weight according EPTA-Procedure 01/2003

6,4 kg

Noise information

Measured values determined according to EN 60745. Typically, the A-weighted noise levels of the tool are:

Sound pressure level (Uncertainty K=3dB(A))

 93,0 dB (A)

Sound power level (Uncertainty K=3dB(A))

104,0 dB (A)

Wear ear protectors!
Vibration information

Vibration total values (triaxial vector sum) determined according to EN 60745
Hammer-drilling into concrete:

Vibration emission value a

h, HD

Uncertainty K=

16,8 m/s

2

1,5 m/s

2

Chiselling:

Vibration emission value a

h, Cheq

Uncertainty K=

16,7 m/s

2

1,5 m/s

2

WARNING!

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 60745

and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different applications,

with different accessories or poorly maintained, the vibration emission may differ. This may significantly increase the exposure level over

the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or when it is

running but not actually doing the job. This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the accessories,

keep the hands warm, organisation of work patterns.

Additional Safety and Working Instructions

Use protective equipment. Always wear safety glasses when

working with the machine. The use of protective clothing is recom-

mended, such as dust mask, protective gloves, sturdy non-slip

footwear, helmet and ear defenders.
The dust produced when using this tool may be harmful to health.

Do not inhale the dust.  Use a dust absorption system and wear a

suitable dust protection mask. Remove deposited dust thoroughly,

e.g. with a vacuum cleaner.
Keep mains lead clear from working range of the machine. Always

lead the cable away behind you.
Do not machine any materials that present a danger to health (e.g.

asbestos).
When working in walls ceiling, or floor, take care to avoid electric

cables and gas or waterpipes.

  WARNING! Read all safety warnings and all instruc-

tions.

 Failure to follow the warnings and instructions may result in

electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

 HAMMER SAFET Y WARNINGS

Wear ear protectors.

  Exposure to noise can cause hearing loss.

Use auxiliary handle(s), if supplied with the tool.

 Loss of

control can cause personal injury.

Hold power tool by insulated gripping surfaces, when

performing an operation where the cutting accessory may

contact hidden wiring or its own cord.

 Cutting accessory con-

tacting a “live” wire may make exposed metal parts of the power

tool “live” and could give the operator an electric shock.
