Seagate IronWolf Product Manual, Rev. A

8

2.0 Drive Specifications

Unless other wise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For
convenience, the phrases

the drive

 and

this drive

 are used throughout this manual to indicate the following drive models:

2.1

Specification summary tables

The specifications listed in

Table 1

 are for quick reference.

For details on specification measurement or definition, refer to the appropriate section of this manual. .

IronWolf models

ST6000VN001

Table 1

Drive specifications summary

Drive Specification*

ST6000VN001

Formatted capacity (512 bytes/sector)**

6000GB (6TB)

Guaranteed sectors

11,721,045,168

Heads

8

Disks

4

Bytes per sector (emulated at 512-byte sectors)

4096 (physical)

Default sectors per track

63

Default read/write heads

16

Default cylinders

16,383

Recording density

2197 kB/in

Track density (avg)

540 ktracks/in

Areal density (avg)

900 Gb/in

2

SATA interface transfer rate

600 MB/s

Maximum data transfer rate

190 MB/s

ATA data-transfer modes supported

PIO modes: 0 to 4

Multiword DMA modes: 0 to 2

Ultra DMA modes 0 to 6

Cache buffer

256MB

Height (max)

26.1mm / 1.028 in

Width (max)

101.6mm (± 0.25) / 4.0 in (± 0.010)

Length (max)

146.99mm / 5.787 in

Weight (typical)

610g / 1.345 lb

Average latency

6.0 ms

Power-on to ready (typ)

15.0s

Standby to ready (typ)

15.0s

Startup current (typical) 12V

1.8A

Voltage tolerance (including noise)

5V ±5%

12V ±10%

Non-Operating (Ambient °C)

–40° to 70°

Operating ambient temperature (min °C)

#

5°

Operating temperature (drive case max °C)

70°

†

Temperature gradient

20°C per hour max (operating)

30°C per hour max (non-operating)

Relative humidity

5% to 90% (operating)

5% to 95% (non-operating)

Relative humidity gradient (max)

30% per hour
