6

 ENGLISH

Open the battery compartment lid, turn to
the direction of the OPEN arrow and insert
a CR 2032, 3V, following the polarity. Close
the battery compartment lid, turning it to in
the direction of the CLOSE arrow.

Usage of the remote control

Functions of the buttons on the remote
control fully correspond to the buttons on
the control panel.
Each pressing of the button is accompa-
nied by a sound signal.
While using the remote control direct it to
the detector situated in the middle of the
indication panel (3). The distance between
the remote control and the unit should not
exceed 5-6 meters.

CLEAN AND CARE

Note! Always switch off and unplug the
unit before cleaning.

Clean the cell evaporator (10), filters (11)
and (12) as soon as they are dirty
1. Unplug the unit.
2.  Remove the grid with the mesh filter (12),

by pressing the clamps. To clean the grid
with filers (12) use a vacuum cleaner with
a corresponding attachment, you can
wash the grid with a filter, using a neutral
detergent and a soft brush. Dry the grid
with the filter before using it.

3. Remove the HEPA-filter (11) from the

unit. To clean the HEPA-filter (11) use a
vacuum cleaner with a corresponding
attachment. Do not wash the НЕРА-filter
with water.

4. Remove the cell evaporator (10) from

the unit. To clean the cell evaporator (10)
use a neutral detergent and a soft brush,
then rinse it with water.

5. Turn the water tank clamp (16) anti

clockwise. Remove the water tank (13).
Drain the remaining water.

6.  Wipe the water tank (13) with a wet cloth,

dampened in a soft detergent, and then
rinse it with water.

7.  Wipe the body of the unit with a dry soft

cloth. Never immerse the unit into water.

8. Do not use abrasives to clean the parts

of the unit.

Delivery set

1.  Fan heater – 1pc.
2.  Remote control – 1pc.
3.  Battery CR 2032 – 1 pc.
4.  Cold accumulators – 2 pcs.
5.  Instruction manual – 1 pc.

SPECIFICATIONS

Power supply: 220-240 V ~ 50 Hz
Power in the heating mode:
1000 W/2000 W
Power in the cooling mode: 65 W
Maximal air flow: not less than 20m

3

/min

Weight: 9,3 kg
Boxed weight: 13 kg
Dimensions: 360х324х798 mm
Noise level: not more than 65dB
Water tank capacity: 6,5 l

Specifications subject to change without
prior notice.

MINIMUM SERVICE LIFE - 5 YEARS

GUARANTEE

Details regarding guarantee conditions can
be obtained from the dealer from whom
the appliance was purchased. The bill of
sale or receipt must be produced when
making any claim under the terms of this
guarantee.

This product conforms to the
EMC-Requirements as laid down
by the Council Directive 89/336/
EEC and to the Law Voltage
Regulation (73/23 EEC)
