www.timberk.com • electric oil filled radiator

5

IMPORTANT!

1. Switch on and operate the radiator only when upright (with

wheels below and control elements above). Any other position

may cause a dangerous situation and result in failure of the oil-

filled radiator or damage of property and the manufacturer will

consider this as a non-warranty case.
2. Do not switch the radiator on, if roller wheels are not installed.

1. Unpack the radiator and roller wheels and remove all the packaging

material.
2. Overturn the radiator on a mat or no soft surface, to avoid damage to

lacquer coating.
3. Install wheel plates on the lower part of radiator sections, into two fixed

supports.
4. Draw up two finger nuts on one side and two finger nuts on the other - in

clamp extensions passed through the wheel plate supports, after making

sure that 2 openings in the wheel plate match together with the clamp

extensions (see Figure 3).
5. Turn the radiator back and tip it up.

6. ASSEMBLY AND INSTALLATION

NOTE:

Design and technical characteristics of the convector

heater, as well as its complete set may be changed by

the manufacturer without prior notification, when it is

needed to improve its quality.

Fig. 2

Fig. 3

1. Read section «Important precautions» carefully unless you already did it.
2. Connect the unit’s power cord to an electric outlet, observing all of the

abovementioned precautions. Remember that you can connect the unit

to electric mains only if the rotating power regulator is in OFF position

(switched off), i.e. the knob is rotated against the stop counterclockwise.
3. It is also preferable to turn the temperature regulating knob against the

stop counterclockwise. Then you can connect the unit to electric mains.
4. Set the unit’s power regulator (knob) to position I, II or III (corresponds to

low, normal and maximum power of unit’s operation). Remember that the

higher the power you choose, the faster the unit heats the air. But at a low

power you save electric power and reduce the load on your electric mains.
5. After you chose the desired operating power in accordance with

your individual preferences, you have to choose the desired heating

temperature. Turning the thermostat knob clockwise (from MIN position

towards MAX position), you thus adjust the temperature mode you need.

Since the moment you choose the temperature mode (provided one or

another power mode is activated  see item 4) the oil filled radiator will start

to operate.
6. During the first minutes of radiator’s operation you may fell a slight smell

of burning. It may be caused by dust on the unit; it will soon disappear.

If necessary, you can perform a preliminary preventive cleaning of the

unit, following rules, set forth in this manual and observing «Important

precautions».
7. When the room temperature will reach the desired level, you should

slowly turn the temperature regulator’s knob counterclockwise (towards

MIN). You will hear a click of the thermostat turning off, and the light on the

7. UNIT OPERATION RULES AND PROCEDURE
