If the unit is used without an earth circuit or this earth circuit is damaged,

we do not recommend you to switch on and operate the air ionizer.

Without grounding the unit can accumulate static electricity on metal

surfaces of the case, and in this case there is a slight chance of an electric

shock due to static electricity.

Unit operation rules and procedure.

1. Read section  Important precautions  carefully unless you already did it.
2. Connect the unit's power cord to an electric outlet, observing all of the

abovementioned precautions. Remember that you can connect the unit

to electric mains only if the rotating power regulator is in OFF position

(switched off ), i.e. the knob is rotated against the stop counterclockwise.
3. It is also preferable to turn the temperature regulating knob against

the stop counterclockwise. Then you can connect the unit to electric

mains.
4. Set the unit's power regulator (knob) to position I, II or III (corresponds

to low, normal and maximum power of unit's operation). Remember that

the higher the power you choose, the faster the unit heats the air. But at

a low power you save electric power and reduce the load on your electric

mains.
5. After you chose the desired operating power in accordance with your

individual preferences, you have to choose the desired heating

temperature. Turning the thermostat knob clockwise (from MIN position

towards MAX position), you thus adjust the temperature mode you need.

Since the moment you choose the temperature mode (provided one or

another power mode is activated  see item 4) the oil filled radiator will

start to operate.
6. During the first minutes of radiator's operation you may fell a slight

smell of burning. It may be caused by dust on the unit; it will soon

disappear. If necessary, you can perform a preliminary preventive

cleaning of the unit, following rules, set forth in this manual and

observing  Important precautions .
7. When the room temperature will reach the desired level, you should

slowly turn the temperature regulator's knob counterclockwise (towards

MIN). You will hear a click of the thermostat turning off, and the light on

the control panel will go out. Now the room temperature will be

maintained at the chosen level.
8. If you need to reduce the room temperature, turn the thermostat knob

counterclockwise. Also you can lower the unit's operating power (I or II).

9. If you need to raise the room temperature, turn the thermostat knob

clockwise (maximum possible position  MAX indicator). Also you can raise

the unit's operating power (II or III).
10. The lines of Timberk oil filled radiators

TOR 31...RRX,  TOR 31...EHX I

are

additionally equipped with a built-in fan heater, located on the front

panel of the unit. To speed up the room heating, activate the fan heater

by pressing the special button switch (the button can be located both on

the front panel of the unit and on the side (to the left) of the front panel

of the unit  depending on the unit line).
Pressing the fan heater button, you must select the ON position (switched

on), upon that power supply will be automatically fed both to the fan

motor and to the built-in heating element. If you need to turn on the fan

heater, please, press the button again, selecting the OFF position

(switched off ).

IMPORTANT!

For the unit to operate normally, the level of voltage in electric mains

must  be  sufficient  in  strict  compliance  with  the  technical  parameters

indicated on the unit. Carefully study the technical label, as well as all

labels with special warnings, attached to the unit's surface.

Cleaning and maintenance of the unit.

1. Remember that you must clean the unit regularly to remove dust from

the surface of heating sections. Dust and dirt on the unit's surface have a

negative effect on the unit's operational efficiency, in some cases a smell

of burning dust can cause a headache and nausea, as well as other

negative health effects. Also a dirty unit cannot operate 100% effectively,

temperature parameters of the room heating can be disrupted.

2. Prior to preventive cleaning of the unit, you must switch off the unit,

unplug it from electric mains (see  Important precautions ) and let the

unit cool down.

3. Clean the unit's sections and other surfaces with a soft, slightly damp

duster/cloth. The cloth must not leave fluff on the unit's surface.

4. It is not recommended to use detergents, including materials

containing abrasive elements.

5. During cleaning, please, do not damage the unit's surface by sharp

objects (hard sponge, polishing paper, etc). Scratches on the painted

surface can result in rusting.

Switch on and use the unit again only having carried out all  Important

precautions ; also make sure that the unit's surface is absolutely dry.
